MEAN WELL IRM-45-12ST [3/4] Irm 45
![MEAN WELL IRM-45-12ST [3/4] Irm 45](/views2/1676321/page3/bg3.png)
Block Diagram
Output Derating VS Input Voltage
INPUT VOLTAGE (VAC) 60Hz
85 10095 120115 160140 200180 240220 264
LOAD (%)
90
100
80
70
60
50
40
Derating Curve
FILTER
I/P
EMI
FILTER
RECTIFIERS
&
RECTIFIERS
CONTROL
PWM
DETECTION
CIRCUIT
&
FILTER
+V
-V
SWITCHING
POWER
fosc : 65KHz
AMBIENT TEMPERATURE (℃)
LOAD (%)
(HORIZONTAL)
70
20
40
50
60
80
100
File Name:IRM-45-SPEC 2015-03-17
45W Single Output Encapsulated Type
IRM-45 series
-30 -25 0-15 15 30 50 60
230VAC
Input only
