Block Diagram
fosc : 100KHz
MFM-20 series
fosc : 100KHz
File Name:MFM-20-SPEC 2017-09-25
2 High Reliable Green Medical On Board Type0W
FILTER
I/P
EMI
FILTER
RECTIFIERS
&
RECTIFIERS
CONTROL
PWM
DETECTION
CIRCUIT
&
FILTER
+V
-V
SWITCHING
POWER
O.L.P.
Output Derating VS Input Voltage
INPUT VOLTAGE (VAC) 60Hz
80 10095 120115 160140 200180 240220 264
LOAD (%)
90
100
80
70
60
50
40
Derating Curve
AMBIENT TEMPERATURE (℃)
LOAD (%)
3.3V,5V
12V~24V
50
100
30
70
(HORIZONTAL)
-30 -20 -10 0 10 20 30 40 50 60 70
80
85-35
25
45
