Block Diagram
Output Derating VS Input Voltage
INPUT VOLTAGE (VAC) 60Hz
80 10095 120115 160140 200180 240220 264
LOAD (%)
90
100
80
70
60
50
40
Derating Curve
fosc : 100KHz
MPM-05 serie s
AMBIENT TEMPERATURE (℃)
LOAD (%)
(HORIZONTAL)
-30 -20 -10 0 10 20 30 40 50 60
100
80
40
70
File Name:MPM-05-SPEC 2017-10-23
80 85
20
-40
FILTER
I/P
EMI
FILTER
RECTIFIERS
&
RECTIFIERS
CONTROL
PWM
DETECTION
CIRCUIT
&
FILTER
+V
-V
SWITCHING
POWER
O.L.P.
5W High Reliable Green Medical Encapsulated Type
