Mechanical SpecificationMechanical Specification
Case No.IRM60 Unit:mm
PCB mounting style (MPM-65)
2-2ψ
2-1ψ
3.5 1mm±
40.75
52
6.75
5
5.5
BOTTOM
VIEW
5.7
76
87
29.5
(MPM-65-xxSTScrew terminal style )
AC/L, AC/N P/N diameter:1ψ
4- 3.5ψ
109
98
6.7
33.5
33
52
7.5
555
File Name:MPM-65-SPEC 2020-10-20
65W AC-DC High Reliable PCB-Mount Green Medical Power Module
MPM-65 series
Installation Manual
Please refer to : http://www.meanwell.com/manual.html
-Vo
+Vo
AC/N
AC/L
+V , -V P/N diameter:2
oo
ψ
AC/N AC/L
-V
o+Vo+Vo-Vo
TOP
VIEW
