SPECIFICATION

MODEL

DCVOLTAGE

RATEDCURRENT

CURRENTRANGE

RATEDPOWER

OUTPUT

LINEREGULATION

LOADREGULATION

SETUP,RISETIME

HOLDUP TIME (Typ.)

VOLTAGERANGE

FREQUENCY RANGE

EFFICIENCY (Typ.)

INPUT

INRUSHCURRENT (Typ.)

WITHSTANDVOLTAGE

ISOLATIONRESISTANCE

WORKINGHUMIDITY

WORKINGTEMP.

STORAGETEMP.,HUMIDITY

TEMP.COEFFICIENT

VIBRATION

MTBF

DIMENSIONOTHERS

NOTE

PACKING

OVERLOAD

OVERVOLTAGE

ACCURRENT (Typ.)

1000ms,20ms/230VAC1000ms,20ms/115VACatfullload

100ms/230VAC24ms/115VACatfullload

85~264VAC120~370VDC

47~440Hz

76%73% 78%

13.8~16.2V

79%

17.25~20.25V

81%

27.6~32.4V

0.35A/115VAC0.2A/230VAC

COLDSTART 30A/115VAC50A/230VAC

Above105% ratedoutputpower

5.75~6.75V3.8~4.95V

Protectiontype: Hiccupmode,recoversautomaticallyafterfaultconditionisremoved

I/P-O/P:4KVAC

I/P-O/P:100MOhms/500VDC /25 /70%RH

20~90%RHnon-condensing

-20~+70 (Referto"DeratingCurve")

-40~+85 ,10~95%RH

0.03%/ (0~50

10~500Hz,2G10min./1cycle,periodfor60min. eachalongX, Y,Zaxes

499.7Khrsmin.MIL-HDBK-217F(25 )

75*53*22.7mm(L*W*H)

0.14Kg;120pcs/17.8Kg/0.97CUFT

FileName:PM-15-SPEC2012-11-28

0.5%

1.0%

0.5%

1.0%

0.5%

1.0%

2.0%

3.0%

2.0% 2.0% 2.0%

80mVp-p80mVp-p 150mVp-p 150mVp-p 240mVp-p

5V3.3V 12V 15V 24V

3A3.5A 1.25A 1A 0.63A

0~3A0~3.5A 0~1.25A 0~1A 0~0.63A

15W11.55W 15W 15W 15.12W

PM-15-5 PM-15-12 PM-15-15 PM-15-24PM-15-3.3

SAFETY STANDARDS

15WOutputSwitchingPowerSupply

PM-15 series

Features :

RIPPLE&NOISE(max.) Note.2

VOLTAGETOLERANCE Note.3

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation.

4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets

EMC directives.

5. .

6. Suitable for BF application with appropriate system consideration.

Touch current was measured from primary input to DC output

ENVIRONMENT

SAFETY &

EMC

(Note4)

PROTECTION

Protectiontype: Shutoffo/pvoltage,clampingbyzenerdiode

CompliancetoEN55011 ,EN55022(CISPR22)ClassB,(CISPR11) EN61000-3-2,-3

CompliancetoEN61000-4-2,3,4,5,6,8,11,EN55024,EN60601-1-2,EN61204-3,medicallevel,criteria A

Universal AC input / Full range

Protections: Short circuit / Overload / Over voltage

Ultra-miniature size, light weight

Cooling by free air convection

Isolation class

Medical safety approved (2 x MOPP between primary to secondary)(Note.6)

No load power consumption<0.5W

100% full load burn-in test

Fixed switching frequency at 67KHz

High reliability

3 years warranty

ANSI/AAMIES60601-1, TUVEN60601-1,IEC60601-1,UL60950-1approved

EMCIMMUNITY

EMCEMISSION

LEAKAGECURRENT Note.5

Touchcurrent<80 A/264VAC
