SPECIFICATION

RSP-100-3.3 RSP-100-5 RSP-100-7.5 RSP-100-12

RSP-100-13.5

RSP-100-15 RSP-100-24 RSP-100-27 RSP-100-48

MODEL

DC VOLTAGE

RATED CURRENT

CURRENT RANGE

RATED POWER

OUTPUT VOLTAGE ADJ. RANGE

LINE REGULATION

LOAD REGULATION

SETUP, RISE TIME

HOLD UP TIME (Typ.)

VOLTAGE RANGE

FREQUENCY RANGE

POWER FACTOR (Typ.)

EFFICIENCY (Typ.)

INPUT

INRUSH CURRENT (Typ.)

LEAKAGE CURRENT

SAFETY STANDARDS

WORKING TEMP.

WORKING HUMIDITY

STORAGE TEMP., HUMIDITY

TEMP. COEFFICIENT

VIBRATION

MTBF

DIMENSIONOTHERS

NOTE

PACKING

OVERLOAD

OVER VOLTAGE

REMOTE CONTROL

FUNCTION

AC CURRENT (Typ.)

3.3V 5V 7.5V 12V 13.5V 15V 24V 27V 48V

20A 20A 13.5A 8.5A 7.5A 6.7A 4.2A 3.8A 2.1A

0 ~ 20A 0 ~ 20A 0 ~ 13.5A 0 ~ 8.5A 0 ~ 7.5A 0 ~ 6.7A 0 ~ 4.2A 0 ~ 3.8A 0 ~ 2.1A

66W 100W 101.25W 102W 101.25W 100.5W 100.8W 102.6W 100.8W

100mVp-p 100mVp-p 100mVp-p 100mVp-p 100mVp-p 100mVp-p 150mVp-p 150mVp-p 250mVp-p

±2.0% ±2.0% ±2.0% ±1.0% ±1.0% ±1.0% ±1.0% ±1.0% ±1.0%

±0.5% ±0.5% ±0.5% ±0.5%

±0.5%

±0.5%±1.0% ±1.0% ±1.0%

600ms, 30ms at full load

16ms at full load

85 ~ 264VAC 120 ~ 370VDC

47 ~ 63Hz

PF>0.93/230VAC PF>0.98/115VAC at full load

83% 86% 87% 86% 86.5% 87% 87% 87% 88%

1.1A/115VAC 0.55A/230VAC

COLD START 30A/230VAC

<2mA / 240VAC

105 ~ 135% rated output power

3.63 ~ 4.46V 5.5 ~ 6.75V

8.25 ~ 10.13V

13.2 ~ 16.2V

14.85 ~ 18.23V

16.5 ~ 20.25V 26.4 ~ 32.4V

29.7 ~ 36.45V

52.8 ~ 64.8V

Protection type : Constant current limiting, recovers automatically after fault condition is removed

Protection type : Shut down o/p voltage, re-power on to recover

CN1: < 0~0.8VDC POWER ON , 4~10VDC POWER OFF

-30 ~ +70 (Refer to "Derating Curve")℃

20 ~ 90% RH non-condensing

-40 ~ +85 , 10 ~ 95% RH non-condensing℃

±℃ ℃0.05%/ (0 ~ 50 )

10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes

288.5K hrs min. MIL-HDBK-217F (25 )℃

179*99*30mm (L*W*H)

0.52Kg; 24pcs/14.5Kg/0.84CUFT

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.℃

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation.

4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets

EMC directives. For guidance on how to perform these EMC tests, please refer to EMI testing of component power supplies.

5. Strongly recommended that external output capacitance should not exceed 5000uF. Only for: RSP-100-3.3/-5/-7.5)(

(as available on http://www.meanwell.com)

File Name:RSP-100-SPEC 2017-10-12

100W Single Output with PFC Function

RSP-100 series

Universal AC input / Full range

Built-in active PFC function

Protections: Short circuit / Overload / Over voltage / Over temperature

Cooling by free air convection

Built-in constant current limiting circuit

1U low profile 30mm

Remote ON-OFF control

LED indicator for power on

Over voltage category Ⅲ

100% full load burn-in test

3 years warranty

■

Features :

RIPPLE & NOISE (max.) Note.2

VOLTAGE TOLERANCE Note.3

WITHSTAND VOLTAGE

ISOLATION RESISTANCE

ENVIRONMENT

SAFETY &

EMC

(Note 4)

PROTECTION

3.14 ~ 3.63V 4.75 ~ 5.5V 7.13 ~ 8.25V 11.4 ~ 13.2V 12.8 ~ 14.9V 22.8 ~ 26.4V 25.7 ~ 29.7V 45.6 ~ 52.8V14.3 ~ 16.5V

EMC IMMUNITY

EMC EMISSION

OVER TEMPERATURE

Shut down o/p voltage, recovers automatically after temperature goes down

Bauar

Sicherheit

egel gema

t gepruft

www.

ID 2000000000

tuv.com

wac g

UL60950-1, TUV EN60950-1, EN61558-1, EN61558-2-16, CCC GB4943 approved

Compliance to EN55032 (CISPR32) Class B, EN61000-3-2,-3, GB9254 class B

Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024, light industry level, criteria A

I/P-O/P:4KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC

I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25 / 70% RH℃

OVER VOLTAGE CATEGORY

According to E 61558, EN50178,EN60664-1, EN62477-1 altitude up to 2000Ⅲ;;N meters
