Gigabyte MZ71-CE0 (rev. 1.x) [10/144] 2 product specifications
![Gigabyte MZ71-CE0 (rev. 1.x) [10/144] 2 product specifications](/views2/1679971/page10/bga.png)
Hardware Installation - 10 -
1-2 Product Specications
CPU AMD EPYC™ 7002 series processor family
Single processor, 7nm, Socket SP3
Up to 64-core, 128 threads per processor
cTDP up to 280W
Socket SP3
Compatible with AMD EPYC™ 7001 series processor family
Chipset System on Chip
Memory 16 x DIMM slots
DDR4 memory supported only
8-Channel memory architecture
RDIMM modules up to 64GB supported
LRDIMM modules up to 128GB supported
Memory speed: Up to 3200/ 2933 MHz
Onboard
Graphics
Integrated in Aspeed® AST2500
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp
LAN MZ71-CE0
2 x 10GbE LAN ports (1 x Broadcom® BCM57416)
1 x 10/100/1000 management LAN
MZ71-CE1
2 x 1GbE LAN ports (1 x Broadcom® BCM5720)
1 x 10/100/1000 management LAN
Expansion Slots *Slot_6: 1 x PCIe x16 (Gen3 x16 bus) slot ( from CPU_0)
* NOTE: PCIe Gen4 x16 supported if using AMD EPYC™ 7002 series processor family
Slot_4: 1 x PCIe x16 (Gen3 x16 bus) slot ( from CPU_0)
Slot_3: 1 x PCIe x16 (Gen3 x16 bus) slot ( from CPU_1)
Slot_2: 1 x PCIe x16 (Gen3 x8 bus) slot ( from CPU_0)
Slot_1: 1 x PCIe x16 (Gen3 x8 bus) slot ( from CPU_1)
Storage Interface
4 x 7-pin SATA 6Gb/s ports
3 x SlimSAS (with 12 x SATA 6Gb/s or 3 x NVMe PCIe Gen3 x4) ports
1 x M.2 slot:
- M-key
- PCIe Gen3 x4*
* NOTE: PCIe Gen4 x4 supported if using AMD EPYC™ 7002 series processor family
- Supports NGFF-2280/22110 cards
2 x NVMe ports:
- SlimSAS 4i type
- PCIe Gen3 x4 per port
