Hardware Installation - 12 -
1-2 Product Specications
CPU
AMD EPYC™ 7002 series processor family
Dual processors, 7nm, Socket SP3
Up to 64-core, 128 threads per processor
TDP up to 225W, cTDP up to 240W
NOTE: If only 1 CPU is installed, some PCIe or memory functions might be
unavailable
Compatible with AMD EPYC™ 7001 series processor family
Chipset
System on Chip
Memory
32 x DIMM slot
DDR4 memory supported only
8-Channel memory architecture
RDIMM modules up to 64GB supported
LRDIMM modules up to 128GB supported
Memory speed: up to 3200MHz (1DPC), 2933MHz (2DPC)
LAN
2 x 1GbE LAN port (1 x Intel® I350-AM2)
1 x 10/100/1000 management LAN
Video
Integrated in Aspeed® AST2500
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp
Expansion Slot
Riser Card CRS2014:
1 x PCIe x16 slot (Gen4 x16), FHFL
Riser Card CRS2026:
2 x PCIe x16 slot (Gen4 x16), FHFL
Riser Card CRS2026:
2 x PCIe x16 slot (Gen4 x16), FHFL
1 x OCP 3.0 mezzanine slot with PCIe Gen4 x16 bandwidth from CPU_0
Supported NCSI function
1 x OCP 2.0 mezzanine slot with PCIe Gen3 x8 bandwidth (Type1, P1, P2)
Supported NCSI function
1 x M.2 slot:
M-key
PCIe Gen3 x4
Supports NGFF-2242/2260/2280/22110 cards
NOTE: Support is not provided for mixed GPU populations
NOTE:
We reserve the right to make any changes to the product specications and product-related
information without prior notice.
Содержание
- R282 z93 1
- User manual 1
- 2019 giga byte technology co ltd all rights reserved the trademarks mentioned in this manual are legally registered to their respective owners 2
- Copyright 2
- Disclaimer 2
- Documentation classifications 2
- For more information 2
- In order to assist in the use of this product gigabyte provides the following types of documentation 2
- Information in this manual is protected by copyright laws and is the property of gigabyte changes to the specifications and features in this manual may be made by gigabyte without prior notice no part of this manual may be reproduced copied translated transmitted or published in any form or by any means without gigabyte s prior written permission 2
- Conventions 3
- The following conventions are used in this user s guide 3
- Server warnings and cautions 4
- Electrostatic discharge esd 5
- Chapter 1 hardware installation 1 7
- Chapter 2 system appearance 7 7
- Chapter 3 system hardware installation 5 7
- Chapter 4 motherboard components 7 7
- Chapter 5 bios setup 1 7
- Table of contents 7
- 2 advanced menu 56 8
- 3 amd cbs menu 83 8
- 4 amd pbs option menu 102 8
- 5 chipset setup menu 105 5 6 server management menu 106 8
- 7 security menu 112 8
- 8 boot menu 115 8
- 11 agesa post codes 130 9
- 12 bios post beep code ami standard 141 9
- 9 save exit menu 119 5 10 abl post codes 120 9
- This page intentionally left blank 10
- 1 installation precautions 11
- Chapter 1 hardware installation 11
- 2 product specifications 12
- 3 system block diagram 15
- This page intentionally left blank 16
- 2 rear view 18
- 3 1 4 5 6 18
- Psu1 psu2 18
- 3 front panel leds and buttons 19
- No name color status description 19
- 2 1 2 2 1 21
- 4 rear system lan leds 21
- 5 power supply unit led 22
- Psu led 22
- 23 system appearance 23
- 6 hard disk drive leds 23
- Led 1 led 2 23
- Note 1 depends on hba utility spec 2 blink cycle depends on hdd s activity signal 3 if hdd is pulled out during rebuilding the disk status of this hdd is regarded as faulty 23
- This page intentionally left blank 24
- Chapter 3 system hardware installation 25
- 1 removing and installing the chassis cover 26
- 2 removing and installing the fan duct 27
- 3 removing and installing the heat sink 28
- 4 removing and installing the cpu 29
- 31 system hardware installation 31
- 5 1 eight channel memory configuration 31
- 5 removing and installing memory 31
- Cpu1 cpu0 31
- Read the following guidelines before you begin to install the memory make sure that the motherboard supports the memory it is recommended that memory of the same capacity brand speed and chips be used always turn off the computer and unplug the power cord from the power outlet before installing the memory to prevent hardware damage memory modules have a foolproof design a memory module can be installed in only one direction if you are unable to insert the memory switch the direction 31
- This motherboard provides 32 ddr4 memory sockets and supports eight channel technology after the memory is installed the bios will automatically detect the specifications and capacity of the memory 31
- 5 2 removing and installing a memory module 32
- 5 3 dimm population table 32
- Before installing a memory module make sure to turn off the computer and unplug the power cord from the power outlet to prevent damage to the memory module be sure to install ddr4 dimms on to this motherboard 32
- Dimm must be populated in sequential alphabetic order starting with bank a when only one dimm is used it must be populated in memory slot a1 32
- Follow these instructions to install a dimm module 32
- Insert the dimm memory module vertically into the dimm slot and push it down 2 close the plastic clip at both edges of the dimm slots to lock the dimm module 3 reverse the installation steps when you want to remove the dimm module 32
- Rdimm maximum frequency supported 32
- System hardware installation 32 32
- 33 system hardware installation 33
- Ds rdimm maximum frequency supported 33
- Lrdimm maximum frequency supported 33
- 6 removing and installing the pcie riser card 34
- 7 1 installing the ocp 3 mezzanine card 36
- 7 installing the mezzanine card 36
- 7 2 installing the ocp 2 mezzanine card 37
- 9 installing and removing an m device 40
- 10 replacing the fan assembly 41
- 11 removing and installing the power supply 42
- 12 cable routing 43
- Onboard sata 43
- Hdd backplane board power 44
- Hdd backplane board signal 44
- Front panel leds and buttons 45
- Front panel usb 3 ports 45
- Gpu card power 46
- 1 motherboard components 47
- Chapter 4 motherboard components 47
- Cpu1 cpu0 47
- 2 jumper settings 49
- 49 motherboard components 49
- Bios defined 49
- Bios recovery mode 49
- Bios_pwd 49
- Bios_rcvr 49
- Clear supervisor password 49
- Cpu1 cpu0 49
- Host_smbus_sel 49
- Normal default 49
- Pmbus_sel 49
- This page intentionally left blank 50
- Bios setup program function keys 51
- Chapter 5 bios setup 51
- Advanced 52
- Amd cbs 52
- Amd pbs option 52
- Chipset 52
- Save exit 52
- Security 52
- Server management 52
- 1 the main menu 53
- 2 advanced menu 56
- 2 1 trusted computing 57
- 2 2 psp firmware versions 58
- 2 3 legacy video select 59
- 2 4 ast2500 super io configuration 60
- 2 5 s5 rtc wake settings 62
- 2 6 serial port console redirection 63
- 2 7 cpu configuration 66
- 2 8 pci subsystem settings 67
- 2 9 usb configuration 69
- 2 10 nvme configuration 71
- 2 11 sata configuration 72
- 2 12 network stack configuration 73
- 2 13 amd mem configuration status 74
- 2 14 iscsi configuration 75
- 2 15 tls auth configuration 76
- 2 16 intel r i350 gigabit network connection 77
- 2 17 vlan configuration 79
- 2 18 mac ipv4 network configuration 81
- 2 19 mac ipv6 network configuration 82
- 3 amd cbs menu 83
- 3 1 valhalla common options 84
- 3 2 df common options 87
- 3 3 umc common options 90
- 3 4 nbio common options 92
- 3 5 fch common options 97
- 3 6 ntb common options 100
- 3 7 soc miscellaneous control 101
- 4 amd pbs option menu 102
- 4 1 ras 103
- 5 chipset setup menu 105
- 6 server management menu 106
- 6 1 system event log 108
- 6 2 view fru information 109
- 6 3 bmc network configuration 110
- 6 4 ipv6 bmc network configuration 111
- 7 security menu 112
- 7 1 secure boot 113
- 8 boot menu 115
- 8 1 uefi network drive bbs priorities 117
- 8 2 uefi application boot priorities 118
- 9 save exit menu 119
- 10 1 start processor test points 120
- 10 2 memory test points 120
- 10 3 pmu test points 120
- 10 abl post codes 120
- 10 4 original post code 121
- 10 5 cpu test points 122
- 10 6 topology test points 122
- 10 7 extended memory test point 122
- 10 8 gnb earlier init 123
- 10 10 abl0 test points 126
- 10 11 abl5 test points 126
- 10 9 pmu test points 126
- 11 1 universal post code 130
- 11 2 0xa1xx for cz only memory postcodes 130
- 11 agesa post codes 130
- 11 3 s3 interface post code 133
- 11 4 pmu post code 133
- 11 5 0xa5xx assigned for agesa psp module 133
- 11 6 0xa9xx 0xaaxx assigned for agesa nbio module 136
- 11 7 0xacxx assigned for agesa ccx module 138
- 11 8 0xadxx assigned for agesa df module 139
- 11 9 0xafxx assigned for agesa fch module 139
- 12 1 pei beep codes 141
- 12 2 dxe beep codes 141
- 12 bios post beep code ami standard 141
