Gigabyte R272-Z32 (rev. 100) [3/132] Conventions

Conventions

The following conventions are used in this user's guide:

NOTE!

Additional information related to the current topic.

CAUTION!

Precautionary measures to

avoid possible hardware or software problems.

WARNING!

Alerts to any damage that might

result from doing or not doing specic actions.
