Hardware Installation - 12 -
1-2 Product Specications
System
Dimension
1U
438 (W) x 43.5 (H) x 730 (D) mm
CPU
AMD EPYC™ 7002 series processor family
Single processor, 7nm technology
Up to 64-core, 128 threads per processor
TDP up to 225W, cTDP up to 240W
Compatible with AMD EPYC™ 7001 series processor family
Chipset
System on Chip
Socket
Socket
Hardware-
Level Root of
Trust Support
Supported
NOTE! The system will take extra time to boot as it goes through RoT
authentication.
Memory
16 x DIMM slots
DDR4 memory supported only
8-Channel memory architecture
RDIMM modules up to 128GB supported
LRDIMM modules up to 128GB supported
Memory speed: Up to 3200*/ 2933 MHz
Note:
* Follow BIOS setting and memory QVL list if running 3200 Mhz with 2DPC
LAN
2 x 1GbE LAN ports (1 x Intel® I350-AM2)
1 x 10/100/1000 management LAN
Video
Integrated in Aspeed® AST2500
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp
