- 12 - Hardware Installation
1-2 Product Specications
CPU w Support for Intel
®
Xeon
®
E5-2600 V3/V4 series processors in the LGA2011
package
w L3 cache varies with CPU
w Supports Dual QuickPath Interconnect up to 9.6GT/s
w Enhanced Intel SpeedStep Technology (EIST)
w Support Intel Virtualization Technology (VT)
Chipset w Intel
®
C612 Express (Wellsburg) Chipset
Memory w 24 x DIMM slots
w DDR4 memory supported only
w Quad channel memory architecture
w ECC RDIMM / LRDIMM modules supported
w Single and dual rank RDIMM modules up to 32GB supported
w 3DS LRDIMM modules up to 128GB supported
w 1.2V modules: 1600/1866/2133/2400 MHz
LAN w Intel
®
I350-BT2 supports dual GbE LAN ports
w 1 x Server Management GbE LAN port
Expansion Slot w 6 x Full-length full-height slots
w 2 x Half-length full-height slots
w 1 x PCIe mezzanine type T (Gen3 x8 bus) slot
Onboard
Graphics
w ASPEED
®
AST2400 supports 16MB DDR3 VRAM
Mass Storage w 12 x 3.5” Hot-Swap HDDs (R280-A3C/R280-F3C/2.5" HDD supported)
w 24 x 2.5” Hot-Swap HDDs (R280-F2O/R280-G2O)
Expander w LSI SAS3x24 12Gb/s expander (R280-A3C Only)
w LSI SAS2x36 6Gb/s expander (R280-F2O/R280-G2O)
System Fans w 4 x 80x80x38mm /14900rpm
USB w 2 x USB 3.0 ports
w 2 x USB 3.0 ports
Internal
Connectors
w 1 x 14-pin ATX main power connector
w 3 x 8-pin ATX power connectors
w 3 x 4-pin ATX 12V power connectors
w 2 x hot-plug power supply connectors
w 2 x Mini-SAS connectors (SATA3 6Gb/s signal)
w 2 x SATA3 6Gb/s connectors
w 2 x CPU fan headers
w 5 x System fan headers
w 1 x Front panel header
w 1 x HDD Back plane borad header
w 1 x TPM module connector
w 1 x Software RAID key connector
w 1 x IPMB connector
