Hardware Installation - 12 -

1-2 Product Specications

System

Dimension

 2U

 438mm (W) x 87.5mm (H) x 820mm (D)

CPU  AMD EPYC™ 7002 series processor family

 Single processor, 7nm technology

 Up to 64-core, 128 threads per processor

 TDP up to 225W, cTDP up to 240W

 Fully support 280W

Compatible with AMD EPYC™ 7001 series processor family

Chipset

 System on Chip

Memory  8 x DIMM slots

 DDR4 memory supported only

 8-Channel memory architecture

 RDIMM modules up to 64GB supported

 LRDIMM modules up to 128GB supported

 Memory speed: Up to 3200 MHz

LAN

(G242-Z10)

 2 x 1GbE LAN ports (1 x Intel® I350-AM2)

 1 x 10/100/1000 management LAN

(G242-Z11)  1 x 10/100/1000 management LAN

Expansion Slot

(G242-Z10)

4 x PCIe x16 slots (Gen3 x16 bus) for GPUs

Riser Card CRSG027:

 1 x PCIe x16 slot (Gen3 x16 or x8), Low prole, half-length

 1 x PCIe x8 slots (Gen3 x0 or x8), Low prole, half-length

1 x OCP 2.0 mezzanine slot with PCIe Gen3 x16 bandwidth (Type1, P1, P2, P3,

P4)

1 x onboard M.2 slot:

 M-key

 PCIe Gen3 x4

 Supports NGFF-2242/2260/2280/22110 cards

 CPU TDP is limited to 180W if using M.2 device

- System is validated for population with a uniform GPU model

- Support is not provided for mixed GPU populations
