Gigabyte H242-Z10 (rev. 100) [12/139] 2 product specifications
![Gigabyte H242-Z10 (rev. 100) [12/139] 2 product specifications](/views2/1681216/page12/bgc.png)
Hardware Installation - 12 -
1-2 Product Specications
System
Dimension
(H242-Z10)
2U 4 Nodes - Rear access
440mm (W) x 87mm (H) x 840mm (D)
(H242-Z11)
2U 4 Nodes - Front access
440mm (W) x 87mm (H) x 840mm (D)
CPU AMD EPYC™ 7002 series processor family
Single processor, 7nm technology
Up to 64-core, 128 threads per processor
TDP up to 225W, cTDP up to 240W
Compatible with AMD EPYC™ 7001 series processor family
Socket
Per Node:
1 x LGA 4094
Total:
4 x LGA 4094
Socket SP3
Chipset System on Chip (SoC)
Memory Per Node:
8 x DIMM slots
Total:
32 x DIMM slots
DDR4 memory supported only
8-Channel memory architecture
RDIMM modules up to 64GB supported
LRDIMM modules up to 128GB supported
Memory speed: Up to 3200 MHz
LAN Per Node:
2 x 1Gb/s BASE-T LAN ports (Intel® I350-AT2)
1 x Dedicated management port
Total:
8 x 1GbE LAN ports (1 x Intel® I350-AM2)
4 x Dedicated management ports
