- 12 - Hardware Installation
1-2 ProductSpecications
CPU 2nd Generation Intel® Xeon® Scalable and Intel® Xeon® Scalable Processors
Intel® Xeon® Platinum Processor, Intel® Xeon® Gold Processor, Intel® Xeon®
Silver Processor and Intel® Xeon® Bronze Processor
NOTE: If only 1 CPU is installed, some PCIe or memory functions might be
unavailable.
Socket Per node:
2 x LGA 3647
Total:
8 x LGA 3647
Socket P0
Mounting pitch: Narrow ILM
Chipset
Intel® C621 Express Chipset
Memory Per node:
16 x DIMM slots
Total:
64 x DIMM slots
DDR4 memory supported only
6-channel memory architecture
RDIMM modules up to 32GB supported
LRDIMM modules up to 64GB supported
Support Intel® Optane™ DC Persistent Memory
1.2V modules: 2933 (1DPC)/2666/2400/2133 MHz
NOTE:
1. 2933MHz for 2nd Generation Intel® Xeon® Scalable Processors only
2. Intel® Optane™ DC Persistent Memory for 2nd Generation Intel® Xeon®
Scalable Processors only
LAN Per node:
2 x 10Gb/s BASE-T LAN ports (Intel® X550-AT2)
1 x Dedicated management port
Total:
8 x 10Gb/s BASE-T LAN ports (Intel® X550-AT2)
4 x Dedicated management ports
1 x 10/100/1000 *CMC global management port
*CMC: Chassis Management Controller, to monitor all status of computing nodes.
Expansion Slot Per node:
1 x Half-length low-prole slot with PCIe x16 (Gen3 x16 bus)
1 x Half-length low-prole slot with PCIe x8 (Gen3 x8 bus)
1 x OCP mezzanine slot with PCIe Gen3 x16 bus
Total:
4 x Half-length low-prole slot with PCIe x16 (Gen3 x16 bus)
4 x Half-length low-prole slot with PCIe x8 (Gen3 x8 bus)
4 x OCP mezzanine slot with PCIe Gen3 x16 bus
