SPECIFICATION

RSP-500-15

RSP-500-12 RSP-500-24 RSP-500-27 RSP-500-48RSP-500-5RSP-500-4RSP-500-3.3

MODEL

DC VOLTAGE

RATED CURRENT

CURRENT RANGE

RATED POWER

RIPPLE & NOISE (max.) Note.2

OUTPUT VOLTAGE ADJ. RANGE

VOLTAGE TOLERANCE Note.3

LINE REGULATION

LOAD REGULATION

SETUP, RISE TIME

HOLD UP TIME (Typ.)

VOLTAGE RANGE Note.4

FREQUENCY RANGE

POWER FACTOR (Typ.)

EFFICIENCY (Typ.)

INPUT

ENVIRONMENT

INRUSH CURRENT (Typ.)

LEAKAGE CURRENT

OVER TEMPERATURE

SAFETY STANDARDS

SAFETY &

EMC

(Note 4)

WITHSTAND VOLTAGE

ISOLATION RESISTANCE

WORKING TEMP.

REMOTE CONTROL

REMOTE SENSE

FAN CONTROL (Typ.)

WORKING HUMIDITY

STORAGE TEMP., HUMIDITY

TEMP. COEFFICIENT

VIBRATION

MTBF

DIMENSIONOTHERS

NOTE

PACKING

OVERLOAD

OVER VOLTAGE

PROTECTION

FUNCTION

15V12V 24V 27V 48V5V4V3.3V

33.4A41.7A 21A 18.6A 10.5A90A90A90A

0 ~ 33.4A0 ~ 41.7A 0 ~ 21A 0 ~ 18.6A 0 ~ 10.5A0 ~ 90A0 ~ 90A0 ~ 90A

501W500.4W 504W 502.2W 504W450W360W297W

150mVp-p150mVp-p 150mVp-p 150mVp-p 150mVp-p150mVp-p120mVp-p120mVp-p

4.5 ~ 5.5V3.6 ~ 4.3V2.8 ~ 3.6V 13.5 ~ 18V10 ~ 13.2V 20 ~ 26.4V 26 ~ 30V 41 ~ 56V

±1.0%±1.0% ±1.0% ±1.0% ±1.0%±2.0%±2.0%±2.0%

±0.3%±0.3% ±0.2% ±0.2% ±0.2%±0.5%±0.5%±0.5%

±0.5%±0.5% ±0.5% ±0.5% ±0.5%

±1.0%±1.0%±1.0%

1500ms, 80ms/230VAC 3000ms, 80ms/115VAC at full load

18ms/230VAC 14ms/115VAC at full load

85 ~ 264VAC 120 ~ 370VDC

47 ~ 63Hz

PF>0.95/230VAC PF>0.98/115VAC at full load

88% 88% 89% 89.5% 90.5%

84%

83%81%

20A/115VAC 40A/230VAC

<2mA / 240VAC

105 ~ 130% rated output power

13.8 ~ 16.2V 18.8 ~ 21.8V 27.6 ~ 32.4V 32.9 ~ 38.3V 58.4 ~ 68V

5.75 ~ 6.75V4.5 ~ 5.3V3.8 ~ 4.5V

Protection type : , recovers automatically after fault condition is removedConstant current limiting

Protection type : Shut down o/p voltage, re-power on to recover

Shut down o/p voltage, recovers automatically after temperature goes down

UL60950-1, TUV EN60950-1 approved

Compliance to EN55032 (CISPR32) Class B, EN61000-3-2,-3

Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024, EN61000-6-2, EN61204-3 heavy industry level, criteria A

I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC

I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25  / 70% RH

-30 ~ +70℃ (Refer to "Derating Curve")

POWER ON:open or 0~0.8VDC between RC+(Pin 4)&RC-(Pin3) on CN100

Compensate voltage drop on the load wiring up to 0.3V

RTH2≧50℃±10℃Fan on ; RTH2≦40℃±10℃ Fan off (Fan always on for 3.3~5V,Fan ON/OFF control for 12~48V)

20 ~ 90% RH non-condensing

-40 ~ +85℃, 10 ~ 95% RH

±0.03%/℃ (0 ~ 50℃)

10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes

187.7K hrs min. MIL-HDBK-217F (25℃ )

230*127*40.5mm (L*W*H)

1.3Kg; 9pcs/12.7Kg/0.7CUFT

■

℃















EMC IMMUNITY

EMC EMISSION

RSP-500 series

500W Single Output with PFC Function

5.3A/115VAC 2.65 A/230VAC

4.2A/115VAC 2.1 A/230VAC

AC CURRENT (Typ.)

File Name:RSP-500-SPEC 2017-07-14

Bauar

Sicherh eit

egel gema

t gepru ft

www.

ID 2000000000

tuv.com

wac g

o s

POWER OFF: 4~10VDC between RC+(Pin 4)&RC-(Pin3) on CN100
