SPECIFICATION

S-100F-5 S-100F-7.5 S-100F-12 S-100F-15 S-100F-24 S-100F-48

MODEL

DCVOLTAGE

RATEDCURRENT

CURRENTRANGE

RATEDPOWER

OUTPUT VOLTAGE ADJ.RANGE

LINEREGULATION

LOADREGULATION

SETUP,RISETIME

HOLDUP TIME (Typ.)

VOLTAGERANGE

FREQUENCY RANGE

EFFICIENCY (Typ.)

INPUT

INRUSHCURRENT (Typ.)

LEAKAGECURRENT

SAFETY STANDARDS

WORKINGTEMP.

WORKINGHUMIDITY

STORAGETEMP.,HUMIDITY

TEMP.COEFFICIENT

VIBRATION

MTBF

DIMENSIONOTHERS

NOTE

PACKING

OVERLOAD

OVERVOLTAGE

ACCURRENT (Typ.)

5V 7.5V 12V 15V 24V 48V

20A 13.5A 8.5A 6.7A 4.5A 2.2A

0~20A 0~13.5A 0~8.5A 0~6.7A 0~4.5A 0~2.2A

100W 101W 102W 100.5W 108W 105.6W

100mVp-p 125mVp-p 125mVp-p 125mVp-p 150mVp-p 150mVp-p

2.0%

4.5~5.5V 6.75~8.25V 10.8~13.2V 13.5~16.5V 21.6~26.4V 43.2~52.8V

1.0% 1.0% 1.0% 1.0% 1.0%

0.5% 0.5% 0.5% 0.5% 0.5% 0.5%

1.0% 0.5% 0.5% 0.5% 0.5% 0.5%

1000ms,30msatfullload

20msatfullload

88~132VAC/176~264VACselectedbyjumperorswitch248~370VDC

47~63Hz

76% 78% 80% 81% 83% 84%

3.15A/115VAC1.5A/230VAC

COLDSTART 20A/115VAC40A/230VAC

<1mA /240VAC

105~150% ratedoutputpower

5.75~6.75V 8.63~10.13V 13.8~16.2V 17.25~20.25V 27.6~32.4V 55.2~64.8V

Protectiontype:Hiccupmode,recoversautomaticallyafterfaultconditionisremoved

-10~+60 (Refertooutputloadderatingcurve)

20~90%RHnon-condensing

-20~+85 ,10~95%RH

0.03%/ (0~50

10~500Hz,2G10min./1cycle,60min.eachalongX, Y,Zaxes

314.9Khrsmin.MIL-HDBK-217F(25 )

199*98*38mm(L*W*H)

0.65Kg;20pcs/14.2Kg/0.8CUFT

FileName:S-100F-SPEC2009-03-04

HARMONICCURRENT

EMSIMMUNITY

Complianceto EN61000-3-2,-3

Complianceto EN61000-4-2,3,4,5,6,8,11;ENV50204,EN55024,lightindustrylevel,criteria A

CSA60950-1(for24Vonly), ,CCCGB4943approvedUL1012,UL60950-1, TUVEN60950-1

CompliancetoEN55022(CISPR22)ClassB

100WSingleOutputSwitchingPowerSupply

AC input range selectable by switch

Protections: Short circuit / Overload / Over voltage

Cooling by free air convection

100% full load burn-in test

Fixed switching frequency at 83KHz

2 years warranty

Features :

S-100F se ri es

RIPPLE&NOISE(max.) Note.2

VOLTAGETOLERANCE Note.3

ENVIRONMENT

SAFETY &

EMC

(Note4)

PROTECTION

EMICONDUCTION&RADIATION

WITHSTANDVOLTAGE

ISOLATIONRESISTANCE

I/P-O/P:3KVACI/P-FG:1.5KVACO/P-FG:0.5KVAC

I/P-O/P,I/P-FG,O/P-FG:100MOhms/500VDC /25 /70%RH

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation.

4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets

EMC directives.

(for 24V only)
