SPECIFICATION

MODEL

DCVOLTAGE

RATEDCURRENT

CURRENTRANGE

RATEDPOWER

OUTPUT

VOLTAGE ADJ.RANGE

LINEREGULATION Note.4

LOADREGULATION Note.5

SETUP,RISETIME

HOLDUP TIME (Typ.)

VOLTAGERANGE

FREQUENCY RANGE

EFFICIENCY(Typ.)

ACCURRENT (Typ.)

INPUT

INRUSHCURRENT (Typ.)

LEAKAGECURRENT

TEMP.COMPENSATION

OUTPUTVOLTAGESENSOR

SAFETY STANDARDS

WORKINGTEMP.

WORKINGHUMIDITY

STORAGETEMP.,HUMIDITY

TEMP.COEFFICIENT

VIBRATION

MTBF

DIMENSIONOTHERS

NOTE

PACKING

OVERLOAD

500ms,30ms/230VAC1200ms,30ms/115VACatfullload

50ms/230VAC 16ms/115VACatfullload

85~264VAC120~370VDC

47~63Hz

81%

1.1A/115VAC0.65A/230VAC

COLDSTART 45A

<2mA /240VAC

4.3~5.8A ratedoutputpower

16.6~19.3V

CompliancetoEN55022(CISPR22)ClassB,EN61000-3-2,3

-20~+60 (Refertooutputloadderatingcurve)℃

20~90%RH non-condensing

-40~+85 ,10~95%RH℃

± ℃ ℃0.03%/ (0~45 )

10~500Hz,2G10min./1cycle,periodfor 60min.eachalongX, Y,Zaxes

495.7Khrsmin.MIL-HDBK-217F(25 )℃

129*98*38mm(L*W*H)

FileName:SCP-50-SPEC2011-05-24

13.8V

3.6A

0~3.6A

49.7W

120mVp-p

± 2.0%

± 1.0%

± 2.0%

SCP-50-12

OVERVOLTAGE

EMCIMMUNITY

CompliancetoEN61000-4-2,3,4,5,6,8,11,ENV50204,EN55024,EN61000-6-1,lightindustrylevel,criteria A

+15,-5%

50WSingleOutputSwitchingPowerSupply

Universal AC input/Full range

Protections: Short circuit / Overload / Over voltage

Cooling by free air convection

100% full load burn-in test

2 years warranty

/ Battery

polarity protections (by fuse)

Built-in temperature compensation function

Output voltage detection signal

LED indicator for power on

No load power consumption <0.75W

■ Features :

SC P- 50 se ri es

RIPPLE&NOISE(max.) Note.2

VOLTAGETOLERANCE Note.3

EMCEMISSION

ENVIRONMENT

SAFETY &

EMC

(Note7)

PROTECTION

WITHSTANDVOLTAGE

ISOLATIONRESISTANCE

I/P-O/P:3KVACI/P-FG:1.5KVACO/P-FG:0.5KVAC

I/P-O/P,I/P-FG,O/P-FG:100MOhms/500VDC/25 /70%RH℃

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation.

4. Line regulation is measured from low line to high line at rated load.

5. Load regulation is measured from 0% to 100% rated load.

6. 33% Duty cycle maximum within every 15 seconds. Average output power should not exceed the rated power.

7. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets

EMC directives.

℃

(As available on http://www.meanwell.com)

Protectiontype: Hiccupmode,recoversautomaticallyafterfaultconditionisremoved

Protectiontype:Shutdowno/pvoltage,re-powerontorecover

0.45Kg;30pcs/14.5Kg/0.95CUFT

UL60950-1,CB(IEC60950-1)approved

2.2~2.9A ratedoutputpower

1.8A

27.6V

2.2A

0~1.8A

49.7W

200mVp-p

± 1.0%

85%

33.1~38.5V

SCP-50-24

+15,-5%

PEAK5S Note.6 4.3A

FUNCTION

ByNTC(notprovidewiththepowersupply)

L=outputvoltage+0.2~0.7V(ACOK);L=0V(ACFail)
