MEAN WELL SP-240-48 Data sheet онлайн

Universal AC input / Full range

Built-in active PFC function, PF>0.95

Protections: Short circuit / Overload / Over voltage / Over temperature

Forced air cooling by built-in DC Fan

Built-in fan ON / OFF control

LED indicator for power on

Fixed switching frequency at 90KHz

3 years warranty

SPECIFICATION

SP-240-5 SP-240-7.5 SP-240-12 SP-240-15 SP-240-24 SP-240-30 SP-240-48

MODEL

DCVOLTAGE

RATEDCURRENT

CURRENTRANGE

RATEDPOWER

RIPPLE&NOISE(max.) Note.2

OUTPUT VOLTAGE ADJ.RANGE

VOLTAGETOLERANCE Note.3

LINEREGULATION

LOADREGULATION

SETUP,RISETIME

HOLDUP TIME (Typ.)

VOLTAGERANGE Note.5

FREQUENCY RANGE

POWERFACTOR (Typ.)

EFFICIENCY (Typ.)

INPUT

ENVIRONMENT

INRUSHCURRENT (Typ.)

ACCURRENT(Typ.)

LEAKAGECURRENT

OVERTEMPERATURE

SAFETY STANDARDS

HARMONICCURRENT

EMICONDUCTION&RADIATION

SAFETY &

FUNCTION

EMSIMMUNITY

EMC

(Note4)

WITHSTANDVOLTAGE

ISOLATIONRESISTANCE

WORKINGTEMP.

FANCONTROL

WORKINGHUMIDITY

STORAGETEMP.,HUMIDITY

TEMP.COEFFICIENT

VIBRATION

MTBF

DIMENSIONOTHERS

NOTE

PACKING

OVERLOAD

OVERVOLTAGE

PROTECTION

5V 7.5V 12V 15V 24V 30V 48V

45A

32A 20A 16A 10A 8A 5A

0~45A 0~32A 0~20A 0~16A 0~10A 0~8A 0~5A

225W 240W 240W 240W 240W 240W 240W

150mVp-p 150mVp-p 150mVp-p 150mVp-p 150mVp-p 150mVp-p 150mVp-p

4~6V 6~9V 10~14V 12~18V 20~28V 27~33V 41~56V

2.0% 2.0% 1.0% 1.0% 1.0% 1.0% 1.0%

0.5% 0.5% 0.3% 0.3%

0.2% 0.2% 0.2%

1.0% 1.0% 0.5% 0.5% 0.5% 0.5% 0.5%

800ms,50ms/230VAC1500ms,50ms/115VACatfullload

20ms/230VAC20ms/115VACatfullload

88~264VAC124~370VDC

47~63Hz

PF>0.95/230VACPF>0.98/115VACatfullload

79%

3.6A/115VAC1.8A/230VAC

83%

9.4~10.9V

14.7~17.5V

19~22.5V

29.5~35V

57.6~67.2V

34.7~41V

86% 86% 87% 89%88%

25A/115VAC40A/230VAC

<2mA /240VAC

105~135%ratedoutputpower

Protectiontype:Hiccupmode,recoversautomaticallyafterfaultconditionisremoved

Protectiontype:Shutdowno/pvoltage,re-powerontorecover

6.3~7.5V

90 5 (5V,7.5V),85 5 (12V,15V,24V,30V,48V)(TSW1:detectonheatsinkofpowertransistor)

Protectiontype:Shutdowno/pvoltage,recoversautomaticallyaftertemperaturegoesdown

UL60950-1, TUVEN60950-1approved

CompliancetoEN55022(CISPR22)ClassB

Complianceto EN61000-3-2,-3

CompliancetoEN61000-4-2,3,4,5,6,8,11;ENV50204,EN55024,lightindustrylevel,criteria A

I/P-O/P:3KVACI/P-FG:1.5KVACO/P-FG:0.5KVAC

I/P-O/P,I/P-FG,O/P-FG:100MOhms/500VDC /25 /70%RH

-20~+70 (Refertooutputloadderatingcurve)

RTH2 40 FANON, 35 FANOFF(Typ.)

20~90%RHnon-condensing

-40~+85 ,10~95%RH

0.03%/ (0~50

10~500Hz,2G10min./1cycle,60min.eachalongX, Y,Zaxes

284Khrsmin.MIL-HDBK-217F(25 )

190*93*50mm(L*W*H)

0.8Kg;18pcs/15.4Kg/1.04CUFT

Features :

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation.

4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets

EMC directives.

5. Derating may be needed under low input voltages. Please check the derating curve for more details.

FileName:SP-240-SPEC2009-09-02

SP-240 se ri es

240WSingleOutputwithPFCFunction
