MEAN WELL SP-750-15 [30/32] Converter
![MEAN WELL SP-750-15 [30/32] Converter](/views2/1677224/page30/bg1e.png)
Picture Model
Output Power
(W)
Input Voltage
(VAC)
Output Voltage
(VDC)
Dimension
(LxWxH) (mm)
Insulation
Fan Fanless
NMP650
650 -
90~264 5 , 12 , 24 , 48
250 x 89 x 41
NMP1K2
1200 - 250 x 127 x 41
RPS-120-x-C
120 90
80~264
12 , 15 , 24 , 27 , 48
103.4 x 62 x 40
RPS-200-x-C 200 140
RPS-300-x-C 300 200 90~264 130 x 86 x 43
RPS-400-x-C 400 250
80~264 12 , 15 , 18 , 24 , 27 , 36, 48
130 x 86x 43
RPS-400-x-TF 400 - 130 x 86 x 66.5
RPS-400-x-SF 400 - 160 x 86 x 43
RPS-500-x-C 500 320 130 x 86x 43
RPS-500-x-TF 500 - 130 x 86 x 66.5
RPS-500-x-SF
500 - 160 x 86 x 43
MSP-100 - 100
85~264
3.3 , 5 , 7.5 , 12 , 15 , 24 , 36 , 48
159 x 97 x 38
MSP-200 - 200 199 x 98 x 38
MSP-300 300 - 199 x 105 x 41
MSP-450 450 - 218 x 105 x 41
MSP-600 600 -
218 x 105 x 63.5
MSP-1000 1000 - 12 , 15 , 24 , 48
Picture Model
Output Power
(W)
Input Voltage
(VAC)
Output Voltage
(VDC)
Dimension
(LxWxH) (mm)
Insulation
Rated Peak (10 sec.)
MFM-05 5 5.5W
80~264
3.3 , 5 , 12 , 15 , 24
42 x 22.3 x 20.5
MFM-10 10 11W
MFM-15 15 16.5W
49 x 23.8 x 23
MFM-20 20 23.8W
MFM-30 30 35W 3.3 , 5 , 12 , 15 , 24 , 48 65.5 x 35 x 23
MPM-05 5 5.5W
80~264
3.3 , 5 , 12 , 15 , 24
45.7 x 25.4 x 21.5
MPM-10 10 11W
MPM-15 15 16.5W
52.4 x 27.2 x 24
MPM-20 20 23.8W
MPM-30 30 35W 69.5 x 39 x 24
MPM-45 45 50.4W
5 , 12 , 15 , 24, 48
87x 52x 29.5
MPM-65 65 71.5W
MPM-90 90 99.2W 12 , 15 , 24, 48
MPM-30-xST 30 35W
80~264
3.3 , 5 , 12 , 15 , 24 , 48 91 x 39.5 x 28.5
MPM-45-xST 45 50.4W
5 , 12 , 15 , 24 , 48
109 x 52 x 33.5
MPM-65-xST 65 71.5W
MPM-90-xST 90 99.2W 12 , 15 , 24 , 48
AC/DC
AC/DC
DC/DC
On Board Type
Enclosed Type
Converter
Picture Model
Rated Power
(W)
Input Voltage
(VDC)
Output Voltage
(VDC)
Dimension
(LxWxH) (mm)
MDS01 1
L : 4.5 ~ 5.5
M: 10.8 ~ 13.2
N: 21.6 ~ 26.4
3.3 , 5 , 12 , 15
19.5 x 9.8 x 12.5
(0.77” x 0.39” x 0.49”)
MDS02 2 5 , 12 , 15
MDD01 1
±5 , ±9 , ±12 , ±15
MDD02 2
MDS15 15
A: 9 ~ 18
B: 18 ~ 36
C: 36 ~ 75
5 , 12 , 15, 24
50.8 x 25.4 x 12
(2” x 1” x 0.47”)
MDS20 20
29
