SPECIFICATION

TP-75A TP-75B TP-75C

MODEL

DCVOLTAGE

RATEDCURRENT

CURRENTRANGE

RATEDPOWER

OUTPUT

VOLTAGE ADJ.RANGE

LINEREGULATION

LOADREGULATION

SETUP,RISETIME

HOLDUP TIME (Typ.)

VOLTAGERANGE Note.5

FREQUENCY RANGE

POWERFACTOR (Typ.)

EFFICIENCY (Typ.)

INPUT

INRUSHCURRENT (Typ.)

LEAKAGECURRENT

SAFETY STANDARDS

HARMONICCURRENT

EMSIMMUNITY

WORKINGTEMP.

WORKINGHUMIDITY

STORAGETEMP.,HUMIDITY

TEMP.COEFFICIENT

VIBRATION

MTBF

DIMENSIONOTHERS

NOTE

PACKING

OVERLOAD

OVERVOLTAGE

ACCURRENT (Typ.)

CH1

12V

CH2

-5V

CH3

CH1

12V

CH2

-12V

CH3

CH1

15V

CH2

-15V

CH3

7A 3A 0.6A 7A 3A 0.4A 6A 2.5A 0.5A

1.5~10A 0.2~4A 0~0.6A 1.5~10A 0.2~4A 0~0.6A 1.5~10A 0.2~3A 0~0.6A

74W 75.8W 75W

100mVp-p 120mVp-p 100mVp-p 100mVp-p 120mVp-p 120mVp-p 100mVp-p 120mVp-p 120mVp-p

3.0% 3.0% 3.0%

CH1:4.75~5.5V

4.0% 4.0% 4.0%

8.0% 8.0% 8.0%

1.0% 1.0% 1.0%1.0% 1.0% 1.0%1.0% 1.0% 1.0%

800ms,60msatfullload

36msatfullload

90~264VAC127~370VDC

47~63Hz

PF>0.95/230VACPF>0.98/115VACatfullload

70%

1.5A/115VAC0.8A/115VAC

COLDSTART 20A/230VAC

<2mA /240VAC

105~150% ratedoutputpower

5.75~6.75Von+5V

Protectiontype:Hiccupmode,recoversautomaticallyafterfaultconditionisremoved

Protectiontype:Shutdowno/pvoltage,re-powerontorecover

UL60950-1, TUVEN60950-1approved

CompliancetoEN55022(CISPR22)ClassB

Complianceto EN61000-3-2,-3

CompliancetoEN61000-4-2,3,4,5,6,8,11;ENV50204,EN55024,lightindustrylevel,criteria A

-10~+60 (Refertooutputloadderatingcurve)

20~90%RHnon-condensing

-20~+85 ,10~95%RH

0.03%/ (0~50

10~500Hz,2G10min./1cycle,60min.eachalongX, Y,Zaxes

198.4Khrsmin.MIL-HDBK-217F(25 )

179*99*33mm(L*W*H)

0.65Kg;20pcs/12.7Kg/0.64CUFT

75W TripleOutputwithPFCFunction

Universal AC input / Full range

Built-in active PFC function, PF>0.95

Protections: Short circuit / Overload / Over voltage

Low profile: 33mm thickness

LED indicator for power on

Cooling by free air convection

Fixed switching frequency at PFC:67KHz PWM:134KHz

3 years warranty

Features :

TP-75 se ri es

RIPPLE&NOISE(max.) Note.2

VOLTAGETOLERANCE Note.3

WITHSTANDVOLTAGE

ISOLATIONRESISTANCE

I/P-O/P:3KVACI/P-FG:1.5KVACO/P-FG:0.5KVAC1min.

I/P-O/P,I/P-FG,O/P-FG:100MOhms/500VDC /25 /70%RH

ENVIRONMENT

SAFETY &

EMC

(Note4)

PROTECTION

EMICONDUCTION&RADIATION

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation.

4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets

EMC directives.

5. Derating may be needed under low input voltages. Please check the derating curve for more details.

For guidance on how to perform these EMC tests, please refer to EMI testing of component power supplies.

(as available on http://www.meanwell.com)

OUTPUTNUMBER

FileName:TP-75-SPEC2010-10-18
