■ Description

APC-8 series is one 8W AC/DC constant current mode single output LED power supply. It accepts

the full range input 90~264VAC and provides four models with different output current, 250mA,

350mA, 500mA and 700mA, respectively, that the small wattage LED applications employ the

most frequently. Exploiting Class II design (without FG pin) and adopting the 94V-0 flame retardant

plastic enclosure, APC-8 ideally fits the entry-level LED applications.

Suitable for LED related

fixture or appliance

(such as LED Decoration

or Advertisement devices)

■ Features ■ Applications

File Name:APC-8-SPEC 2018-01-05

■ Model Encoding

- 350

APC -

Output current

Output wattage

Series name

8W Single Output Switching Power Supply

APC-8 series



Constant current design

Universal AC input / Full range

Class power unit, no FGⅡ

Fully isolated plastic case

IP42 design

Small and compact size

Cooling by free air convection

Protection:Short circuit

No load power consumption <0.5W

100% full load burn-in test

Low cost / High reliability

2 years warranty

IP42

IS 15885(Part 2/Sec13)

R-41027766
