THD< 20% when output loading 75% at 115VAC/230VAC input and output loading 80% at 277VAC input≧≧

TOTAL HARMONIC DISTORTION

MAX. No. of PSUs on 16A

CIRCUIT BREAKER

32 units (circuit breaker of type B) / 32 units (circuit breaker of type C) at 230VAC

60W Single Output LED Power Supply

CEN-60 series

CEN-60-54

0 ~ 1.15A

62.1W

59 ~ 65V

40.5 ~ 54V

49 ~ 58V

0.9 ~ 1.15A

Universal AC input / Full range (up to 295VAC)

Protections: Short circuit / / Over voltage / Over temperatureOver current

Output voltage and constant current level adjustable

Built-in active PFC function

IP66 design for indoor or outdoor installations

Class 2 power unit

Cooling by free air convection

100% full load burn-in test

High reliability

Suitable for LED lighting and moving sign applications

Compliance to worldwide safety regulations for lighting

Suitable for dry / damp / wet locations

3 years warranty

■

Features :

SPECIFICATION

MODEL CEN-60-20 CEN-60-24 CEN-60-30 CEN-60-36CEN-60-12 CEN-60-15 CEN-60-48CEN-60-42

DC VOLTAGE

CURRENT RANGE

RATED POWER

OUTPUT

LINE REGULATION

LOAD REGULATION

SETUP TIME

VOLTAGE RANGE

Note.4

FREQUENCY RANGE

POWER FACTOR (Typ.)

EFFICIENCY (Typ.)

AC CURRENT (Typ.)

INPUT

INRUSH CURRENT (Typ.)

LEAKAGE CURRENT

WORKING TEMP.

WORKING HUMIDITY

STORAGE TEMP., HUMIDITY

TEMP. COEFFICIENT

VIBRATION

MTBF

DIMENSION

OTHERS

NOTE

PACKING

OVER CURRENT

SHORT CIRCUIT

OVER VOLTAGE

OVER TEMPERATURE

20V 24V 30V 36V 54V12V 15V 48V42V

0 ~ 3A 0 ~ 2.5A 0 ~ 2A 0 ~ 1.7A0 ~ 5A 0 ~ 4A 0 ~ 1.3A0 ~ 1.45A

60W 60W 60W 61.2W60W 60W 62.4W60.9W

1.8Vp-p 2.4Vp-p 3Vp-p 3.6Vp-p 5Vp-p2Vp-p 2.4Vp-p 4.6Vp-p4Vp-p

±10%

±3.0%

±5.0%

500ms / 230VAC 1200ms / 115VAC at full load

90 ~ 295VAC 127 ~ 417VDC

47 ~ 63Hz

PF>0.97/115VAC, PF>0.95/230VAC, PF>0.9/277VAC at full load (Please refer to "Power Factor Characteristic" curve)

88% 89% 90% 90% 91%86% 87% 91%90%

22.8 ~ 26V 28 ~ 34V 34 ~ 38V 41 ~ 46V14.5 ~ 17V 17.5 ~ 21V 54 ~ 60V

47 ~ 52V

0.8A/115VAC 0.4A/230VAC 0.3A/277VAC

COLD START 45A(twidth=85 s measured at 50% Ipeak) at 230VACμ

<0.75mA / 240VAC

95 ~ 110%

Protection type : Constant current limiting, recovers automatically after fault condition is removed

Hiccup mode, recovers automatically after fault condition is removed

-30 ~ +70 (Refer to "Derating Curve")℃

20 ~ 95% RH non-condensing

-40 ~ +80 , 10 ~ 95% RH℃

±℃ ℃0.03%/ (0 ~ 50 )

10 ~ 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes

523.4Khrs min. MIL-HDBK-217F (25 )℃

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.℃

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation.

4. Derating may be needed under low input voltage. Please check the static characteristics for more details.

5. lease refer to "DRIVING METHODS OF LED MODULE".

6. The power supply is considered as a component that will be operated in combination with final equipment. Since EMC performance will be affected by the

complete installation, the final equipment manufacturers must re-qualify EMC Directive on the complete installation again.

7. Direct connecting to LEDs is suggested, but is not suitable for using additional drivers.

8. To fulfill requirements of the latest ErP regulation for lighting fixtures, this LED power supply can only be used behind a switch without permanently

connected to the mains.

0.6Kg;24pcs/15.4Kg/1.29CUFT

Protection type : Shut down o/p voltage, re-power on to recover

RIPPLE & NOISE (max.) Note.2

VOLTAGE TOLERANCE Note.3

ENVIRONMENT

SAFETY &

EMC

PROTECTION

Shut down o/p voltage, re-power on to recover

WITHSTAND VOLTAGE

ISOLATION RESISTANCE

I/P-O/P:3.75KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC

I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25 / 70% RH℃

SAFETY STANDARDS

Compliance to EN55015, EN61000-3-2 Class C ( 75% load) ; EN61000-3-3, EAC TP TC 020≧

Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024, EN61547, light industry level (surge 4KV), criteria B, EAC TP TC 020

15 ~ 20V 18 ~ 24V 22.5 ~ 30V 27 ~ 36V9 ~ 12V 11.25 ~ 15V 36 ~ 48V31.5 ~ 42V

RATED CURRENT 3A 2.5A 2A 1.7A 1.15A5A 4A 1.3A1.45A

17 ~ 22V 22 ~ 27V 27 ~ 33V 33 ~ 40V10.8 ~ 13.5V 13.5 ~ 17V 43 ~ 53V37 ~ 46VVOLTAGE ADJ. RANGE

(SVR1)

CURRENT ADJ. RANGE(SVR2)

2.3 ~ 3A 1.9 ~ 2.5A 1.5 ~ 2A 1.3 ~ 1.7A

3.75 ~ 5A 3 ~ 4A 1 ~ 1.3A1.1 ~ 1.45A

IP66

110

SELV

UL879, UL8750, CSA C22.2 No. 207-M89, CSA C22.2 No. 250.0-08, TUV EN61347-1, EN61347-2-13, IP66, J61347-1, J61347-2-13,

BIS IS15885(for 36V,48V,54V only), EAC TP TC 004 approved

185*62.5*40.5mm (L*W*H)

EMC IMMUNITY

EMC EMISSION

CONSTANT CURRENT REGION

Note.5

File Name:CEN-60-SPEC 2018-01-08

Bauar

Sicherheit

egel gema

tgepruft

www.

ID 2000000000

tuv.com

wac g

IS 15885(Part 2/Sec13)

R-41027766

THOMAS SAMUEL

(for 36V,48V,54V only)
