MEAN WELL CEN-75-15 [2/3] T case
![MEAN WELL CEN-75-15 [2/3] T case](/views2/1683893/page2/bg2.png)
Mechanical Specification
File Name:CEN-75-SPEC 2018-01-08
Case No.993B Unit:mm
Derating Curve Static Characteristics
AMBIENT TEMPERATURE ( )℃
LOAD (%)
-30 -25 -5 0 15 30 50 60 70
20
40
60
80
100
INPUT VOLTAGE (V) 60Hz
90 100 125 135 145 155 165 175 180 200 230 295
100
90
80
70
60
50
40
LOAD (%)
(HORIZONTAL)
fosc : 50KHz(115VAC)
75KHz(230VAC)
DETECTION
PWM & PFC
CIRCUIT
O.L.P.
EMI FILTER
RECTIFIERS
POWER
SWITCHING
FILTER
&
RECTIFIERS
+V
-V
I/P
FG
CONTROL
O.V.P.
&
O.C.P.
300 20±
FG (Green/Yellow)
AC/L(Brown)
AC/N(Blue)
62.5
300 20±
-V(Black)
+V(Red)
7.6
10.5
164
185
40.5
30.6
45
ψ×4.6 4PL
81
Tcase
31.25
※ T case: Max. Case Temperature.
SJTW 18AWG 3C×
SVT 18AWG 2C×
IoVo
ADJ.ADJ.
75W Single Output LED Power Supply
CEN-75 series
Block Diagram
