![MEAN WELL CLG-100-12 [3/3] Clg 10](/views2/1683926/page3/bg3.png)
0.76
0.78
0.80
0.82
0.84
0.86
0.88
0.90
0.92
0.94
0.96
0.98
1.00
50% 60% 70% 80% 90% 100%
115V
230V
277V
68
70
72
74
76
78
80
82
84
86
88
90
92
10% 20% 30% 40% 50% 60% 70% 80% 90% 100%
115V
230V
277V
CLG-100 series possess superior working efficiency that up to 88.5% can be reached in field applications.
EFFICIENCY (%)
LOAD
Power Factor Characteristic
EFFICIENCY vs LOAD (48V Model)
Constant Current Mode
PF
LOAD
There are two major kinds of LED drive method "direct drive" and "with LED driver".
A typical LED power supply may either work in "constant voltage mode (CV) or constant current mode (CC)" to drive the LEDs.
Mean Well's LED power supply with CV+ CC characteristic can be operated at both CV mode [with LED driver, at area (A)] and CC mode [direct drive, at area (B)].
DRIVING METHODS OF LED MODULE
(100W)
File Name:CLG-100-SPEC 2017-06-30
100W Single Output Switching Power Supply
CLG-100 series
Typical LED power supply I-V curve
Vo(%)
100
75
50 100
(min.)
Io (%)
Constant
Current area
Hiccup
Protection
Constant
Voltage area
(A)
(B)
(C)
In the constant current region, the highest voltage at the output of the driver
depends on the configuration of the end systems.
Should there be any compatibility issues, please contact MEAN WELL.
