Mechanical Specification
File Name:CLG-60-SPEC 2017-06-30
Case No. 957A Unit:mm
Derating Curve Static Characteristics
AMBIENT TEMPERATURE ( )℃
LOAD (%)
-30 -25 -5 0 15 30 50 60 70
20
40
60
80
100
INPUT VOLTAGE (V) 60Hz
90 100 125 135 145 155 165 175 180 200 230 295
100
90
80
70
60
50
40
LOAD (%)
(HORIZONTAL)
fosc : 90KHz(115VAC)
120KHz(230VAC)
195.6
171.8
11.9
9.6
ψ×4.2 4PL
61.5
46.5
32
300 20±
-V(Blue)
38.8
+V(Brown)
300 20±
SJOW 17AWG H05RN-F 1.0mm 2C&ײ
SJOW 17AWG H05RN-F 1.0mm 3C&ײ
FG (Green/Yellow)
AC/L(Brown)
AC/N(Blue)
DETECTION
PWM & PFC
CIRCUIT
O.L.P.
EMI FILTER
RECTIFIERS
POWER
SWITCHING
FILTER
&
RECTIFIERS
+V
-V
I/P
FG
CONTROL
O.V.P.
&
O.C.P.
85.9
Tcase
30.75
※ T case: Max. Case Temperature.
60W Single Output LED Power Supply
CLG-60 series
Block Diagram
