DALI Bus Power Supply
DLP- 04 series
35
58.4
90
63.65
45.15
54.5
35
2
1
34
Terminal Pin No. Assignment
Pin No.
Pin No.
2
1
3
4
Assignment
Assignment
DA-
DA+
AC/N
AC/L
ADMISSIBLE DIN RAIL TS OR TS- : 35/7.5 35/15
(Unit:mm,tolerance 0.5mm)±
Case No.985A Unit:mm
File Name:DLP-04-SPEC 2018-08-16
※ R-Type
