CASE NO.: 262A Unit:mm
tc
※ Blank-Type (for 12V model)
‧ : Max. Case Temperature
tc
144~200W Constant Voltage + Constant Current LED Driver
300±20
300±20
Vo+(Red)
Vo-(Black)
SJOW 17AWGx2C
ACL(Brown)
ACN(Blue)
90
32
233
244
220
53.8
71
37.5
37
4-ψ4.5
SJTW 14AWGx2C
2
&H05RN-F 1.0mm
MECHANICAL SPECIFICATION
tc
※ Blank-Type (for other models)
‧ : Max. Case Temperature
tc
300±20
300±20
Vo+(Red)
Vo-(Black)
SJOW 17AWGx2C
ACL(Brown)
ACN(Blue)
90
32
SJOW 17AWGx2C
233
244
220
53.8
71
37.5
37
4-ψ4.5
2
&H05RN-F 1.0mm
2
&05RN-F 1.0mm
ELG-200 series
File Name:ELG-200-SPEC 2020-09-25
