English
2 3
Fatal1ty X99 Professional/3.1 Series
1.2 Specications
Platform
•
EATX Form Factor
•
8 Layer PCB
•
4 x 2oz copper
•
High Density Glass Fabric PCB
CPU
•
Supports Intel® Core
TM
i7 and Xeon® 18-Core Processors
Family for the LGA 2011-3 Socket
•
Digi Power design
•
12 Power Phase design (Supports up to 1300w)
•
Supports Intel® Turbo Boost 2.0 Technology
•
Supports Untied Overclocking Technology
Chipset
•
Intel® X99
Memory
•
Quad Channel DDR4 Memory Technology
•
8 x DDR4 DIMM Slots
•
Supports DDR4 3400+(OC)*/2933(OC)/2800(OC)/2400(
OC)/2133 non-ECC, un-buered memory
* Please refer to Memory Support List on ASRock's website for
more information. (http://www.asrock.com/)
•
Supports non-ECC x8 (8 bit) RDIMM (Registered DIMM)/
x8 (8 bit) UDIMM
•
Supports DDR4 ECC x8 (8 bit) RDIMM/x8 (8 bit) UDIMM
with Intel® Xeon® processors E5 series in the LGA 2011-3
Socket
•
Max. capacity of system memory: 128GB (see CAUTION)
•
Supports Intel® Extreme Memory Prole (XMP) 2.0
Expansion
Slot
•
5 x PCI Express 3.0 x16 Slots (PCIE1/PCIE2/PCIE3/PCIE4/
PCIE5: single at x16 (PCIE1); dual at x16 (PCIE1) / x16
(PCIE4); triple at x8 (PCIE1) / x8 (PCIE2) / x16 (PCIE4);
quad at x8 (PCIE1) / x8 (PCIE2) / x8 (PCIE4) / x8 (PCIE5))
* If you install CPU with 28 lanes, PCIE1/PCIE2/PCIE3/PCIE4/
PCIE5 will run at x16/x0/x4/x8/x0 or x8/x8/x4/x8/x0, and PCIE5
will be disabled.
* To support 3-Way CrossFireX
TM
and 3-Way SLI
TM
when using
CPU with 28 lanes, please install VGA cards to PCIE1/PCIE2/
PCIE4 (x8/x8/x8).
