ASRock Fatal1ty X99X Killer/3.1 [10/110] Specifications
![ASRock Fatal1ty X99X Killer/3.1 [10/110] Specifications](/views2/1686130/page10/bga.png)
English
Fatal1ty X99X Killer/3.1 Series
2
1.2 Specications
Platform
•
ATX Form Factor
•
2oz Copper PCB
•
High Density Glass Fabric PCB
•
Multiple Filter Cap (MFC) (Filter dierent noise by 3
dierent capacitors: DIP solid cap, POSCAP and MLCC)
CPU
•
Supports Intel® Core
TM
i7 and Xeon® 18-Core Processors
Family for the LGA 2011-3 Socket
•
Digi Power design
•
12 Power Phase design
•
Supports Intel® Turbo Boost 2.0 Technology
•
Supports Untied Overclocking Technology
Chipset
•
Intel® X99
Memory
•
Quad Channel DDR4 Memory Technology
•
8 x DDR4 DIMM Slots
•
Supports DDR4 3200+(OC)*/2933(OC)/2800(OC)/2400
(OC)/2133 non-ECC, un-buered memory
* Please refer to Memory Support List on ASRock's website for
more information. (http://www.asrock.com/)
•
Supports non-ECC RDIMM (Registered DIMM)
•
Supports DDR4 ECC, un-buered memory/RDIMM with
Intel® Xeon® processors E5 series in the LGA 2011-3 Socket
•
Max. capacity of system memory: 128GB (see CAUTION)
•
Supports Intel® Extreme Memory Prole (XMP) 2.0
Expansion
Slot
•
3 x PCI Express 3.0 x16 Slots (PCIE1 @ x16 mode; PCIE3 @
x16 mode; PCIE5 @ x8 mode)
* If you install CPU with 28 lanes, PCIE1/PCIE3/PCIE5 will run
at x16/x8/x4.
* If M.2 PCI Express module is installed, PCIE5 will be disabled.
•
2 x PCI Express 2.0 x1 Slots
•
1 x mini-PCI Express Slot
•
Supports AMD Quad CrossFireX
TM
, 3-Way CrossFireX
TM
and CrossFireX
TM
•
Supports NVIDIA® Quad SLI
TM
, 3-Way SLI
TM
and SLI
TM
* If you install CPU with 28 lanes, 3-Way SLI
TM
is not supported.
