UR82 Universal Controller

Vivanco GmbH, Ewige Weide 15, D-22926 Ahrensburg, e-Mail: hotline@vivanco.de 1

( GB ) Operating Instructions -> 1

( D ) Bedienungsanleitung -> 2

( F ) Notice d'emploi -> 3

( E ) Instrucciones de uso ->4

( I ) Istruzioni per l’uso->6

( NL ) Gebruiksaanwijzing -> 7

( PL ) Instrukcja obsługi -> 8

( P ) Instruções de operação -> 9

(DK) Betjeningsvejledning -> 11

(S) Bruksanvisning -> 12

(RUS)

   ->

(GR)  ->15

(TR)

Kullanma talimatı -> 16

(CZ)

Návod k obsluze -> 17

(SK) Návod na obsluhu-> 18

(H) Kezelési utasítása -> 20

(GB) Instructions

Inserting the batteries

Open the battery flap on the back of the

remote control, press the tongue lightly

downwards, then insert 2 alkaline AAA

batteries. Check that the polarity markings on

the batteries and in the battery compartment

are correctly lined up (+=+), then close the flap

carefully. – Always use undamaged batteries.

Adapting to a device (e.g. TV or DVB Set

Top Box (or SAT/Cable) etc.

In order to control e.g. your TV or DVB you

must adapt or set the remote control to it.

There are two ways of doing so: direct control

code entry or code search.

If your UR82 does not understand you it blinks

and you can then repeat the entry. Each

understood entry is confirmed by LED blinking

briefly.

Direct control code entry using the

enclosed list

Example: setting to control a Panasonic

television set:

1. The enclosed list gives, for example, the

Panasonic Code 153.

2. To prepare code entry, briefly press the

SET button, and then the TV-button, until the

Powerkey lamp/LED lights constantly.

3. Then press the number buttons (e.g. 1 5 3)

in sequence.

4. Once the numbers have been entered the

button lamp goes out and the remote control is

ready to control your appliance.

5. Finally, test the control code setting by

trying to control your television set. If it does

not work at all or not correctly try a different

code from the list or the code search (see

below).

Code search

If the brand of your appliance is not in the list

or none of the codes given fits, we recommend

a code search.

Manual code search

1. Switch on the appliance to be controlled.

Program is running.

2. To prepare the code search, briefly press

the SET button and then additionally a

appliance button, e.g. the TV or DVB button,

until the lamp (LED) lights constantly.

3. Then point the remote control at the

appliance to be controlled.

4. Briefly press the ON/OFF (appliance

on/off) button once. The lamp (LED) blinks.

5. Press the ON/OFF (appliance on/off)

button repeatedly, approx. every second, until

appliance, reacts. - If you notice the reaction of

your appliance too late and the next code has

already been emitted you can go back by

pressing SET and then ON/OFF again. If your

appliance has switched itself off you must

switch it back on again, e.g. on the appliance

or with the original remote control, to continue

searching. - When your appliance reacts you

can also try out other buttons without

interrupting the search. If some buttons do not

work properly, simply continue searching with

ON/OFF.

6. When your appliance reacts correctly,

press the appliance button e.g. TV and end the

search. The lamp (LED) goes out.

- The search stops after approx. 30 seconds of

inactivity.

Automatic code search

Your remote control finds the correct settings

almost automatically in seconds:

1. Switch on the appliance to be controlled so

that you can watch a TV program.

2. To start the code search, press the SET

button, and then additionally the appliance

button e.g. TV or DVB, for more than 3

seconds until the Power-key lamp (LED) starts

to blink.

3. Then point the remote control at the

appliance to be controlled while the remote

control emits a different ON/OFF signal every

2 seconds.

4. When your appliance reacts, press any

button, except SET, to end the search. – If you

ended the search too late, continue to search

using the Manual Code Search (see above).

5. Finally, test the control code setting by

trying to control your appliance. If it does not

work correctly, please try the code search

again. The code search then begins with the

next code in the sequence. - Remember to

switch your appliance back on again if you

wish to continue searching.

Code identification

You can read off the 3-digit codes you have

set at any time:

1. Press the appliance button of the appliance

whose code you want to read off, e.g. TV.

2. Press the SET button and additionally 1,2

or 3, depending on the part of the code you

want to read off. For example, if you press

SET+1 and the code 153 (in this example) has

been set, the lamp blinks once after SET+1 is

released to show that the hundred figure is 1.

All you have to do is count. The ten figure is

indicated after SET+2 is released, e.g. it blinks

5 times for the 5 in 153. The one figure is
