No. Description
1 ATX 12V Power Connector (ATX12V1)
2 CPU Fan Connector (CPU_FAN1)
3 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
4 Chassis/Water Pump Fan Connector (CHA_FAN1/WP)
5 ATX Power Connector (ATXPWR1)
6 USB 2.0 Header (USB_9_10)
7 USB 3.1 Gen1 Header (USB_11_12)
8 SATA3 Connector (SATA3_2)
9 SATA3 Connector (SATA3_3)
10 Clear CMOS Jumper (CLRMOS1)
11 SATA3 Connector (SATA3_0)
12 SATA3 Connector (SATA3_1)
13 Chassis/Water Pump Fan Connector (CHA_FAN2/WP)
14 System Panel Header (PANEL1)
15 Chassis Intrusion and Speaker Header (SPK_CI1)
16 USB 2.0 Header (USB_7_8)
17 COM Port Header (COM1)
18 Print Port Header (LPT1)
19 TPM Header (TPMS1)
20 Front Panel Audio Header (HD_AUDIO1)
