H110M-HDV R3.0 / H110M-HDS R3.0 / H110M-DVS R3.0 / H110M-DGS R3.0
•
HDMI Bağlantı Noktasıyla Otomatik Dudak Senkronizasyonu,
Derin Renk (12bpc), xvYCC ve HBR (Yüksek Bit Oranlı
Ses) özelliklerini destekler (Uyumlu bir HDMI monitörü
kullanılmalıdır)
•
Hızlandırılmış Medya Kodlayıcıları-Kod Çözücüleri Destekler
HEVC, VP8, VP9
•
DVI-D ve HDMI Bağlantı Noktalarıyla HDCP destekler
•
DVI-D ve HDMI Bağlantı Noktalarıyla Tam HD 1080p Blu-
ray (BD) kayıttan yürütme destekler
H110M-HDS R3.0:
•
Çi grak çıkışı: Bağımsız ekran denetleyicileriyle DVI-D ve
HDMI bağlantı noktalarını destekler
•
4K x 2K (4096x2160) @ 24Hz / (3840x2160) @ 30Hz'e kadar
maksimum çözünürlükte HDMI destekler
•
1920x1200 @ 60Hz'ye kadar maksimum çözünürlükte DVI-D
işlevini destekler
•
HDMI Bağlantı Noktasıyla Otomatik Dudak Senkronizasyonu,
Derin Renk (12bpc), xvYCC ve HBR (Yüksek Bit Oranlı
Ses) özelliklerini destekler (Uyumlu bir HDMI monitörü
kullanılmalıdır)
•
Hızlandırılmış Medya Kodlayıcıları-Kod Çözücüleri Destekler
HEVC, VP8, VP9
•
DVI-D ve HDMI Bağlantı Noktalarıyla HDCP destekler
•
DVI-D ve HDMI Bağlantı Noktalarıyla Tam HD 1080p Blu-
ray (BD) kayıttan yürütme destekler
H110M-DVS R3.0:
•
Çi grak çıkışı: Bağımsız ekran denetleyicileriyle DVI-D ve
D-Sub bağlantı noktalarını destekler
•
1920x1200 @ 60Hz'ye kadar maksimum çözünürlükte DVI-D
işlevini destekler
•
1920x1200 @ 60Hz'ye kadar maksimum çözünürlükte D-Sub
işlevini destekler
•
Hızlandırılmış Medya Kodlayıcıları-Kod Çözücüleri Destekler
HEVC, VP8, VP9
•
DVI-D Bağlantı Noktalarıyla HDCP destekler
•
DVI-D Bağlantı Noktalarıyla Tam HD 1080p Blu-ray (BD)
kayıttan yürütme destekler
H110M-DGS R3.0:
•
1920x1200 @ 60Hz'ye kadar maksimum çözünürlükte DVI-D
işlevini destekler
•
Hızlandırılmış Medya Kodlayıcıları-Kod Çözücüleri Destekler
HEVC, VP8, VP9
