ASRock Z77 Extreme3 [15/81] Motherboard layout
![ASRock Z77 Extreme3 [15/81] Motherboard layout](/views2/1687548/page15/bgf.png)
15
1.3 Motherboard Layout
1 ATX 12V Power Connector (ATX12V1)
2 1155-Pin CPU Socket
3 CPU Fan Connector (CPU_FAN1)
4 CPU Fan Connector (CPU_FAN2)
5 Power Fan Connector (PWR_FAN1)
6 2 x 240-pin DDR3 DIMM Slots
(DDR3_A1, DDR3_B1, Black)
7 2 x 240-pin DDR3 DIMM Slots
(DDR3_A2, DDR3_B2, Black)
8 ATX Power Connector (ATXPWR1)
9 USB 3.0 Header (USB3_2_3, Black)
10 Chassis Fan Connector (CHA_FAN3)
11 Intel Z77 Chipset
12 SATA3 Connectors (SATA3_0_1, Gray)
13 SATA2 Connectors (SATA2_2_3, Black)
14 SATA2 Connectors (SATA2_4_5, Black)
15 Chassis Speaker Header (SPEAKER1, Black)
16 System Panel Header (PANEL1, Black)
17 Power LED Header (PLED1)
18 Clear CMOS Jumper (CLRCMOS1)
19 SPI Flash Memory (64Mb)
20 Chassis Fan Connector (CHA_FAN1)
21 USB 2.0 Header (USB6_7, Black)
22 USB 2.0 Header (USB4_5, Black)
23 Consumer Infrared Module Header
(CIR1, Gray)
24 COM Port Header (COM1)
25 HDMI_SPDIF Header
(HDMI_SPDIF1, Black)
26 Infrared Module Header (IR1)
27 Front Panel Audio Header
(HD_AUDIO1, Black)
28 PCI Express 2.0 x16 Slot (PCIE4, Black)
29 PCI Slot (PCI2, Black)
30 PCI Express 3.0 x16 Slot (PCIE3, Black)
31 PCI Slot (PCI1, Black)
32 PCI Express 3.0 x16 Slot (PCIE2, Black)
33 PCI Express 2.0 x1 Slot (PCIE1, Black)
34 Chassis Fan Connector (CHA_FAN2)
Intel
Z77
64Mb
BI O S
DDR3_ A2 (64 b it, 240- pin modu le)
DDR3_ A1 (64 b it, 240- pin modu le)
DDR3_ B2 (64 b it, 240- pin modu le)
DDR3_ B1 (64 b it, 240- pin modu le)
ATX12 V1
CPU_ FAN1
CMOS
Batte ry
Super
I/O
USB 2.0
T: USB 0
B: U SB1
PS2
Key boar d
ATXPWR 1
1
USB3 _2_3
CPU_ FAN2
AUDI O
CODE C
LAN
PHY
1
HD_A UDIO1
1
HDMI _SPDIF 1
COM1
1
CLRC MOS1
1
IR1
1
CIR1
1
USB6 _7
1
HDLED RE SET
PLED P WRBTN
PANEL1
1
PLED1
1
1
SPEAKE R1
PCIE1
PCIE2
PCIE3
PCI1
CHA_ FAN1
HDMI1
USB 3. 0
T: US B0
B: USB 1
Top:
RJ- 45
USB 2. 0
T: USB2
B: US B3
21.8cm (8.6 in)
30.5cm (12.0 in)
1
2
3 4
5
6
7
8
9
10
11
12
13
14
18
19
15
16
17
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
DDR3 2800+
RoHS
Front USB 3.0
Z77 Extreme3
X
Fast USB
X
Fast LAN
PCI Express 3 .0
ErP/EuP Ready
X
ast RAMF
Top:
SID E SP K
Cen ter:
REA R SP K
Bot tom:
CTR B ASS
Top:
LIN E IN
Cen ter:
FRO NT
Bot tom:
MIC I N
USB4 _5
1
PWR_ FAN1
PCIE4
PCI2
CHA_ FAN2 CHA_ FAN3
VGA1
DVI1
SATA2 _4_5 SATA2 _2_3 SATA3 _0_1
