1.3 Motherboard Layout
1 CPU Fan Connector (CPU_FAN2)
2 Power Fan Connector (PWR_FAN1)
3 CPU Fan Connector (CPU_FAN1)
4 ATX 12V Power Connector (ATX12V1)
5 1155-Pin CPU Socket
6 2 x 240-pin DDR3 DIMM Slots
(DDR3_A1, DDR3_B1, Black)
7 2 x 240-pin DDR3 DIMM Slots
(DDR3_A2, DDR3_B2, Black)
8 ATX Power Connector (ATXPWR1)
9 USB 3.0 Header (USB3_12_13, Black)
10 Intel H77 Chipset
11 SPI Flash Memory (64Mb)
12 SATA3 Connectors (SATA3_A0_A1, Gray)
13 SATA3 Connectors (SATA3_0_1, Gray)
14 SATA2 Connectors (SATA2_2_3, Black)
15 Clear CMOS Jumper (CLRCMOS1)
16 Chassis Speaker Header (SPEAKER1, Black)
17 Power LED Header (PLED1)
18 System Panel Header (PANEL1, Black)
19 Infrared Module Header (IR1)
20 SATA2 Connector (SATA2_5, Black)
21 SATA2 Connector (SATA2_4, Black)
22 Chassis Fan Connector (CHA_FAN1)
23 USB 2.0 Header (USB_10_11, Black)
24 USB 2.0 Header (USB_8_9, Black)
25 USB 2.0 Header (USB_6_7, Black)
26 Consumer Infrared Module Header
(CIR1, Gray)
27 COM Port Header (COM1)
28 Print Port Header (LPT1)
29 PCI Express 2.0 x16 Slot (PCIE4, Black)
30 PCI Express 2.0 x16 Slot (PCIE3, Black)
31 PCI Express 2.0 x1 Slot (PCIE2, Black)
32 PCI Express 3.0 x16 Slot (PCIE1, Black)
33 Front Panel Audio Header
(HD_AUDIO1, Black)
34 HDMI_SPDIF Header
(HDMI_SPDIF1, Black)
35 Chassis Fan Connector (CHA_FAN2)
Intel
H77
CHA_ FAN2
64M b
BIO S
DDR3_ A2 (64 b it, 2 40- pin m odu le)
DDR3_ A1 (64 b it, 2 40- pin m odu le)
DDR3_ B2 (64 b it, 2 40- pin m odu le)
DDR3_ B1 (64 b it, 2 40- pin m odu le)
ATX12 V1
CPU_ FAN1
CMOS
Batte ry
Super
I/ O
USB 2.0
T: US B0
B: USB1
PS2
Key boa rd
ATXPWR1
1
USB3 _12_1 3
CPU_ FAN2
AUDIO
CODEC
LAN
PHY
PCIE2
PCIE1
VGA1
DVI 1
eSATA
USB 2.0
T: US B2
B: USB3
HDM I
Top:
RJ- 45
USB 3.0
T: US B4
B: USB5
Top:
Cent ral/B ass
Cent er:
REAR SP K
Top:
LINE IN
Cent er:
FRON T
Bott om:
Opti cal
SPDI F
Bott om:
MIC IN
24.4cm (9.6 in)
24.4cm (9.6 in)
Front USB 3. 0
PCIE3
CLRC MOS1
1
PLED1
1
1
SPEAKE R1
IR1
1
HDLED RESE T
PLED P WRBTN
PANEL1
1
SATA2_5
SATA2_4
USB_ 6_7
1
CIR1
1
USB_ 8_9
1
1
USB_ 10_11
1
HDMI _SPDI F1
COM1
1
1
HD_A UDIO1
PWR_ FAN1
DDR3
PCI Express 3.0
H77 Pro4-M
ErP/EuP R eady
RoHS
X
Fast RAM
XFas t LA N
XFas t US B
Designe d in Taipei
LPT1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
18
19
15
16
17
20
21
2223
24
25
26
27
28
29
30
31
32
33
SATA3_A 0_A1
SATA3_0 _1
SATA2_2 _3
PCIE4
34
CHA_ FAN1
35
