12
1.3 Two SLI
TM
Graphics Card Support List
(for Windows
®
XP / XP 64-bit / Vista
TM
/ Vista
TM
64-bit / 7 / 7 64-bit)
* For the latest updates of the supported PCI Express VGA card list for SLI
TM
Mode,
please visit our website for details.
ASRock website: http://www.asrock.com/support/index.htm
Chipset Model Name Chipset Name Driver
Vendor
NVIDIA
ASUS EN9800GT TDP/HTDP/512M GeForce 9800GT 257.21
Chaintech GES96GT-A1512P GeForce 9600 GT 257.21
Gigabyte GV-NX88T256H GeForce 8800 GT 257.21
GIGABYTE GV- N295-18I-B GeForce GTX295 257.21
GIGABYTE GV-N26-896H-B GeForce GTX 260 257.21
LEADTEK PX9800 GTX+ GeForce 9800GTX+ 257.21
LEADTEK PX9800GTX GeForce 9800GTX 257.21
LEADTEK PX8800 GTX TDH GeForce 8800 GTX 257.21
LEADTEK GTX275/896M-DDR3 GeForce GTX275 257.21
MSI NX8600GT-T2D256E GeForce 8600 GT 257.21
MSI N465GTX-M2D1G-B GeForce GTX465 257.21
MSI N250GTS-2D512-OC GeForce GTS 250 257.21
SPARKLE SF-PX98GX221024D3-NHM GeForce 9800GTX2 257.21
