![ASRock H61M-DPS [30/51] Especifi cações](/views2/1687979/page30/bg1e.png)
30
ASRock H61M-DPS Motherboard
Especifi cações
Plataforma - Formato Micro ATX
- Condensador Solid para alimentação da CPU
CPU
- Suporta Intel
®
Core
TM
i7 / i5 / i3 de 3ª e 2ª geração no pacote
LGA1155
- Suporta a tecnologia Intel
®
Turbo Boost 2.0
- Suporta K-Series CPU
Chipsets - Intel
®
H61
- Suporta a tecnologia Rapid Start da Intel
®
e a tecnologia
Smart Connect
Memória - Suporte à tecnologia de memória de duplo canal
- 2 x slots de DDR3 DIMM
- Suporte para memória não intermédia DDR3 1600/1333/1066,
não ECC (DDR3 1600 com Intel
®
Ivy Bridge CPU, DDR3 1333
com processadores Intel
®
Sandy Bridge CPU)
- Capacidade máxima de memória do sistema: 16GB
- Suporta Extreme Memory Profi le (XMP)1.3/1.2 da Intel
®
com
CPU Ivy Bridge da Intel
®
Slots de - 1 x slot de PCI Express 3.0 x16 (modo PCIE1 @ x16)
Expansão * O modo PCIE 3.0 apenas é suportado com a CPU Ivy Bridge
da Intel
®
A CPU Sandy Bridge da Intel
®
apenas suporta o
modo PCIE 2.0.
- 1 x slot de PCI Express 2.0 x1
- 1 x slot de PCI
VGA integrado * As saídas Intel
®
HD Graphics Built-in Visuals e VGA são
suportadas apenas por processadores com GPU integrada.
- Suporta Intel
®
HD Graphics Embutido Visuals: Intel
®
Quick
Sync Video 2.0, Intel
®
InTru
TM
3D, Intel
®
Clear Video HD
Technology, Intel
®
Insider
TM
, Intel
®
HD Graphics 2500/4000
com
CPU Ivy Bridge da Intel
®
- Suporta Intel
®
HD Graphics Embutido Visuals: Intel
®
Quick
Sync Video, Intel
®
InTru
TM
3D, Intel
®
Clear Video HD
Technology, Intel
®
HD Graphics 2000/3000, Intel
®
Advanced
Vector Extensions (AVX) com CPU Sandy Bridge da Intel
®
- Pixel Shader 5.0, DirectX 11 com Intel
®
Ivy Bridge CPU, Pixel
Shader 4.1, DirectX 10.1 com processadores Intel
®
Sandy
Bridge CPU
- Memória partilhada máxima 1760MB com CPU Ivy Bridge da
Intel
®
. Memória partilhada máxima 1759MB com CPU Sandy
Bridge da Intel
®
.
Português
