MECHANICAL SPECIFICATION
70~100W Constant Current Mode LED Driver
ELG-100-C series
CASE NO.: 244A Unit:mm
※ Blank-Type
tc
: Max. Case Temperature
※ A-Type
tc
tc
: Max. Case Temperature
tc
188
199
175
300±20
300±20
45.8
63
35.5
35
AC/L(Brown)
AC/N(Blue)
105
20
4- 4.5ψ
188
199
175
300±20
300±20
45.8
63
35.5
35
AC/L(Brown)
AC/N(Blue)
43.2
17.05
105
20
4- 4.5ψ
Vo+(Brown)
Vo-(Blue)
SJOW 17AWGx2C
&H05RN-F 1.0mm
2
SJOW 17AWGx2C
&H05RN-F 1.0mm
2
Vo+(Brown)
Vo-(Blue)
SJOW 17AWGx2C
&H05RN-F 1.0mm
2
SJOW 17AWGx2C
&H05RN-F 1.0mm
2
File Name:ELG-100-C-SPEC 2018-05-29
