INPUT
OUTPUT
OUT
PUT
INPUT
1-10VDC
DALI to PW
M
M
CoCo
Co
Co
Co
Co
o
nv
nv
nv
nv
nv
v
v
nv
n
erer
er
er
er
er
er
r
er
r
r
e
te
te
te
te
te
te
te
te
te
te
t
e
te
rr
r
r
r
r
r
r
r
r
r
r
r
r
84
Features
• Convert DALI signal to PWM signal
• Comply with DALI standards (IEC62386-101,102,207)
• Universal AC input (90 to 305VAC)
• 4 DALI addressable output channels
• Built-in push dim function
• Linear or logarithm dimming curve selectable
(comply with IEC62386-207)
• Built-in relay for ON/OFF control of LED PSU
• Fully isolated plastic case
• Class II, no FG
Model No. DAP-04 DAP-04-S01
AC input voltage range 90~305VAC ; 127~431VDC
Power consumption(typ.) 0.5W
Dimming range 1~100%
Output signal PWM, 1KHz
Output channel 4 channels with 4 DALI addresses 4 channels with 4 or 1 DALI address selectable
Output PWM logic Active high or active low selectable Active high
Working temperature -30~+60
O
C (refer to output derating curve)
Safety standards EN61347-1, EN61347-2-11, EN61058-1 clause 8/17/20/25, EAC TP TC 004 approved
DALI standards Comply with IEC62386-101, 102, 207
EMC standards EN55015, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, EN61547, EAC TP TC 020
Dimension(LxWxH)(mm) 165x 46x 23
Connection of Dimming Operation
źź
DALI Dimming Solution
Push Dimming Solution
• Power consumption<0.5W
• Suitable to use along with
MEAN WELL's AC/DC LED PSU with 3-in-1 dimming
function
• Two models for choice:
Blank-Type: 4 channels with 4 DALI addresses
S01-Type: 4 channels with 4 or 1DALI address selectable
• 3 years warranty
