7
Audio - 7.1 CH HD Audio with Content Protection
- DAC with 110dB dynamic range (VIA
®
VT2020 Audio Codec)
- Supports HDMI Audio with Dolby True HD and DTS HD Master
Audio (when Intel
®
Core
TM
i5 600 series / i3 500 series /
Pentium
®
G6950 CPU is installed)
- Premium Blu-ray audio support
LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111DL
- Supports Wake-On-LAN
Rear Panel I/O I/O Panel
- 1 x PS/2 Keyboard Port
- 1 x VGA/D-Sub Port
- 1 x VGA/DVI-D Port
- 1 x HDMI Port
- 1 x Optical SPDIF Out Port
- 5 x Ready-to-Use USB 2.0 Ports
- 1 x eSATA3 Connector
- 1 x Ready-to-Use USB 3.0 Port
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
- 1 x IEEE 1394 Port
- HD Audio Jack: Rear Speaker/Central/Bass/Line in/Front
Speaker/Microphone (see CAUTION 10)
SATA3 - 2 x SATA3 6.0Gb/s connectors by Marvell SE9123/9120,
support NCQ, AHCI and “Hot Plug” functions (SATA3_2
connector is shared with eSATA3 port)
USB 3.0 - 1 x USB3.0 port by Fresco FL1000G, supports USB 3.0 up to
5Gb/s
Connector - 6 x SATAII 3.0Gb/s connectors, support NCQ, AHCI and “Hot
Plug” functions
- 2 x SATA3 6.0Gb/s connectors
- 1 x IR header
- 1 x COM port header
- 1 x HDMI_SPDIF header
- 1 x IEEE 1394 header
- 1 x Chassis Intrusion header
- 1 x Power LED header
- CPU/Chassis/Power FAN connector
- 24 pin ATX power connector
- 8 pin 12V power connector
- Front panel audio connector
