ASRock AD525PV3 [29/44] 2 9 2 9 2 9 2 9

2929

VCORE Voltage

Use this to select VCORE Voltage. Configuration options: [Auto], [1.00V]

to [1.15V]. The default value of this feature is [Auto].

VCCM(DRAM) Voltage

Use this to select VCCM(DRAM) Voltage. Configuration options: [Auto],

[1.30V] to [2.05V]. The default value of this feature is [Auto].

+1.05V Voltage

Use this to select +1.05V Voltage. Configuration options: [Auto], [1.050V]

to [1.200V]. The default value of this feature is [Auto].

+1.5V Voltage

Use this to select +1.5V Voltage. Configuration options: [Auto], [1.509V] to

[1.604V]. The default value of this feature is [Auto].

Would you like to save current setting user defaults?

In this option, you are allowed to load and save three user defaults

according to your own requirements.
