MEAN WELL ELG-150-C2100AB [10/12] File name elg 150 c spec 2018 09 30
![MEAN WELL ELG-150-C2100AB [10/12] File name elg 150 c spec 2018 09 30](/views2/1688247/page10/bga.png)
208
219
195
300±20
300±20
45.8
63
35.5
35
AC/L(Brown)
AC/N(Blue)
105
20
※ B DA/D2-Type/
※ A-Type(for 1750mA, 2100mA models)
208
219
195
300±20
300±20
45.8
63
35.5
35
AC/L(Brown)
AC/N(Blue)
50
21.5
105
20
4- 4.5ψ
4- 4.5ψ
105~150W Constant Current Mode LED Driver
ELG-150-C series
tc
: Max. Case Temperature
tc
tc
: Max. Case Temperature
tc
* DIM+ for B-Type
DA+ for DA-Type
PROG+ for D2-Type
* *DIM- for B-Type
DA- for DA-Type
PROG- for D2-Type
SJOW 17AWGx2C
&H05RN-F 1.0mm
2
SJOW 17AWGx2C
&H05RN-F 1.0mm
2
Vo+(Brown)
Vo-(Blue)
DIM-(Black)**
DIM+( )*Gray
Vo+(Brown)
Vo-(Blue)
SJOW 17AWGx2C
&H05RN-F 1.0mm
2
SJOW 17AWGx2C
&H05RN-F 1.0mm
2
SJOW 17AWGx2C
&H05RN-F 1.0mm
2
File Name:ELG-150-C-SPEC 2018-09-30
