150~200W Constant Current Mode LED Driver
ELG-200-C series
※ AB-Type
tc
: Max. Case Temperature
tc
233
244
220
300±20
300±20
37.5
37
AC/L(Brown)
AC/N(Blue)
53.8
71
79
32
DIM-(Black)
DIM+( )Gray
4- 4.5ψ
SJOW 17AWGx2C
&H05RN-F 1.0mm
2
Vo+(Brown)
Vo-(Blue)
SJOW 17AWGx2C
&H05RN-F 1.0mm
2
File Name:ELG-200-C-SPEC 2018-09-30
※ B/DA/D2-Type
tc
: Max. Case Temperature
tc
* DIM+ for B-Type
DA+ for DA-Type
PROG+ for D2-Type
* *DIM- for B-Type
DA- for DA-Type
PROG- for D2-Type
233
244
220
300±20
300±20
37.5
37
AC/L(Brown)
AC/N(Blue)
53.8
71
79
32
DIM-(Black)**
DIM+( )*Gray
4- 4.5ψ
SJOW 17AWGx2C
&H05RN-F 1.0mm
2
Vo+(Brown)
Vo-(Blue)
SJOW 17AWGx2C
&H05RN-F 1.0mm
2
41.75
19
