DRAM CAS# Latency

Use this item to adjust the means of memory accessing. Configuration

options are [6], [5], [4], [3], and [Auto].

Advance DRAM Configuration

This allows you to select the advanced DRAM configuration. The default

value is [Auto].

Primary Graphics Adapter

This item shows the primary graphics adapter. The default value is [PCI].

Configuration options: [PCI] and [PCI Express].

OnBoard HD Audio

Select [Auto], [Enabled] or [Disabled] for the onboard HD Audio feature. If

you select [Auto], the onboard HD Audio will be disabled when PCI Sound

Card is plugged.

Front Panel

Select [Auto], [Enabled] or [Disabled] for the onboard HD Audio Front Panel.

CD-In

Use this item to enable or disable CD-In of OnBoard HD Audio. If you plan to

use this motherboard to submit Windows

Vista

logo test, please disable

this option.

OnBoard Lan

This allows you to enable or disable the “OnBoard Lan” feature.

PCI Fix Function

This allows you to enable or disable PCI Fix Function. The default value is

[Enabled]. If this item is set to [Enabled], PCI frequency can be fixed at

33.3 MHz. If this item is set to [Disabled], PCI clock can be synchronized to

PCIE clock.

VCCM Voltage

Use this to select VCCM Voltage. Configuration options: [High], [Normal],

[Low], and [Auto]. The default value of this feature is [Auto].

+1.5V Voltage

Configuration options: [High] and [Normal]. The default value of this feature

is [Normal].
