AGP/PCI Fix Frequency: Use this item to select AGP frequency to run

synchronous or asychronous with the CPU host frequency among the

following sets of values: [72 MHz / 36 MHz], [64 MHz / 32 MHz],

[77 MHz / 39 MHz], [67 MHz / 34 MHz], and the default value is [Sync].

No-Excute Memory Protection: No-Execution (NX) Memory Protection Tech

nology is an enhancement to the IA-32 Intel Architecture. An IA-32 proces

sor with “No Execute (NX) Memory Protection” can prevent data pages

from being used by malicious software to execute code. This option will be

hidden if the current CPU does not support No-Excute Memory Protection.

P4 input strobe delay control: This option controls strobe timing between

CPU and northbridge.

P4 input data delay control:

Output DQS control: This option allows you to control the Output DQS. The

default setting is [Auto]. When setting is [Manual], the next option [Output

DQS] will be adjustable.

Output DQS: It allows you to adjust Output DQS as [+0.0ns], [+0.2ns], [+0.

and [+0.6ns].

IDE Driving: This option will help you to control IDE I/O buffer driving strength.

62V] and [2.55V].

This option controls data timing between CPU and

fault setting is

northbridge.

4ns],

The default setting is [Normal].
