MODEL
2-PIPE
FWP02AT FWP03AT FWP04AT FWP05AT FWP06AT FWP07AT
Cooling capacity Total capacity High kW 2.61 (1) 3.14 (1) 3.49 (1) 5.08 (1) 5.45 (1) 6.47 (1)
Sensible capacity
High kW 1.88 (1) 2.16 (1) 2.34 (1) 3.6 (1) 3.87 (1) 4.4 (1)
Heating capacity 2-Pipe High kW 5.47 (2) 6.01 (2) 6.47 (2) 10.31 (2) 11.39 (2) 12.28 (2)
4-Pipe High kW 3.14 (2) 5.99 (2)
Power input High W 46.4 80
Dimensions Unit
HeightxWidthxDepth
mm 239x1,039x609 239x1,389x609
Weight Unit kg 23 24 26 31 33 35
Operation weight kg 24 26 28 33 35 38
Heat exchanger Water volume l 1.1 1.5 2.2 1.6 2.1 3.2
Additional heat exchanger
Water volume l 0.4 0.6
Water ow Cooling l/h 448 (3) 539 (3) 598 (3) 873 (3) 936 (3) 1,111(3)
Heating l/h 480 (3) 527 (3) 567 (3) 904 (3) 999 (3) 1,077 (3)
Additional heat exchanger l/h 275 (3) 526 (3)
Water pressure
drop
Cooling kPa 8 (3) 14 (3) 11 (3) 15 (3) 8 (3) 14 (3)
Heating kPa 7 (3) 10 (3) 8 (3) 12 (3) 7 (3) 10 (3)
Additional heat exchanger kPa 3 (3) 5 (3)
Fan Type Centrifugal - forward blades - directly coupled on fan motor
Air ow rate High m³/h 400 (4) 800 (4)
Available pressure
High Pa 71 65
Sound power level High dBA 55.6 60.6
Sound pressure level
High dBA 44.1 49.1
Piping connections
Drain OD mm 16
Water connections Std. heat exchanger inch 3/4
Add. heat exchanger inch 3/4
Power supply Phase/Frequency/Voltage Hz/V 1~/50/230
MODEL
2-PIPE 4-PIPE
FWZ,R,S02AT FWZ,R,S03AT FWZ,R,S06AT FWZ,R,S08AT FWZ,R,S02AF FWZ,R,S03AF FWZ,R,S06AF FWZ,R,S08AF
Cooling capacity
Total capacity High kW 2.64 (1) 4.96 (1) 6.32 (1) 10.08 (1) 2.64 (3) 4.96 (3) 6.32 (3) 10.08 (3)
Sensible capacity
High kW 1.95 (1) 3.60 (1) 4.80 (1) 7.43 (1) 1.95 (3) 3.60 (3) 4.80 (3) 7.43 (3)
Heating capacity
2-Pipe High kW 3.47 (2) 6.40 (2) 7.51 (2) 11.18 (2) -
4-Pipe High kW - 2.46 (4) 4.19 (4) 6.45 (4) 10.06 (4)
Power input High W 57.4 82.7 101.4 147 57.4 82.7 101.4 147
Current input
High A 0.50 0.72 0.88 1.27 0.50 0.72 0.88 1.27
Low A 0.05 0.07 0.09 0.05 0.07 0.09
Dimensions
FWZ & FWR
Unit
HeightxWidthx-
Depth
mm
564x774x226 564x987x226 564x1,194x226 564x1,404x251 564x774x226 564x987x226 564x1,194x226 564x1,404x251
Dimensions FWS
535x584x224 535x794x224 535x1,004x224 535x1,214x249 535x584x224 535x794x224 535x1,214x249 535x1,004x224
Weight FWZ
Unit kg
20 25 31 41 21 26 33 44
Weight FWR 21 27 33 44 22 28 35 46
Weight FWS 15 19 23 32 16 20 34 25
Heat exchanger Water volume l 0.7 1 1.4 2.1 0.7 1 1.4 2.1
Additional heat exchanger
Water volume l - 0.2 0.3 0.4 0.6
Water ow
Cooling l/h 454 (5) 853 (5) 1,084 (5) 1,728 (5) 454 (5) 853 (5) 1,084 (5) 1,728 (5)
Heating l/h 454 (5) 853 (5) 1,084 (5) 1,728 (5) 216 (5) 367 (5) 565 (5) 882 (5)
Water pressure
drop
Cooling kPa 20 (5) 29 (5) 24 (5) 25 (5) 20 (5) 29 (5) 24 (5) 25 (5)
Heating kPa 16 (5) 23 (5) 19 (5) 20 (5) 11 (5) 9 (5) 14 (5) 45 (5)
Fan
Type Centrifugal multi-blade, double suction
Air ow rate High m³/h 560 (6) 900 (6) 1,200 (6) 1,660 (6) 560 (6) 900 (6) 1,200 (6) 1,660 (6)
Sound power level
High dBA 62 70 64 71 62 70 64 71
Piping
connections
Water
Inlet 1/2” 1/2” 3/4”
Outlet 1/2” 1/2” 3/4”
Drain FWZ & FWS
OD mm 16
Power supply Phase/Frequency/Voltage Hz/V 1~/50/230
Heating & Cooling
(1) Cooling: 2 pipe: air 27°CDB, 19°CWB; entering water 7°C; leaving water 12°C
(2) Heating: 2 pipe: air 20°CDB, entering water 50°C, water ow as per cooling mode
(3) Cooling: 4 pipe: air 27°CDB, 19°CWB; entering water 7°C; leaving water 12°C
(4) Heating: 4 pipe: air 20°CDB; entering water 70°C; leaving water 60°C
(5) Water ow rate and water pressure drop values are at maximum speed
(6) Air ow rate at 0Pa ESP
(1)Cooling: 2 pipe: air 27°CDB, 19°CWB; entering water 7°C; leaving water 12°C
(2)Heating: 2 pipe: air 20°CDB; entering water 70°C; leaving water 60°C
(3) Water ow rate and water pressure drop values are at maximum speed
(4) Air ow at 0Pa ESP
