2.4 Expansion Slots (PCI and AGP Slots)

There are 5 PCI slots and 1 AGP slot on P4S55FX+ / P4S55FX motherboard.

PCI slots: PCI slots are used to install expansion cards that have the 32-bit PCI

interface.

AGP slot: The AGP slot is used to install a graphics card. The ASRock AGP slot has

a special locking mechanism which can securely fasten the graphics

card inserted.

Please do NOT use a 3.3V AGP card on the AGP slot of this motherboard!

It may cause permanent damage! For the voltage information of your

AGP card, please check with the AGP card vendors.

Installing an expansion card

Step 1. Before installing the expansion card, please make sure that the power

supply is switched off or the power cord is unplugged. Please read the

documentation of the expansion card and make necessary hardware

settings for the card before you start the installation.

Step 2. Remove the system unit cover (if your motherboard is already installed in a

chassis).

Step 3. Remove the bracket facing the slot that you intend to use. Keep the screws

for later use.

Step 4. Align the card connector with the slot and press firmly until the card is

completely seated on the slot.

Step 5. Fasten the card to the chassis with screws.

Step 6. Replace the system cover.
