English
3
X570 Steel Legend WiFi ax
AMD Ryzen series CPUs (Pinnacle Ridge)
•
2 x PCI Express 3.0 x16 Slots (single at x16 (PCIE1); dual at
x16 (PCIE1) / x4 (PCIE4))*
AMD Ryzen series CPUs (Picasso)
•
2 x PCI Express 3.0 x16 Slots (single at x8 (PCIE1); dual at x8
(PCIE1) / x4 (PCIE4))*
* Supports NVMe SSD as boot disks
•
3 x PCI Express 4.0 x1 Slots
•
Supports AMD Quad CrossFireX
TM
and CrossFireX
TM
•
1 x M.2 Socket (Key E) with the bundled WiFi-802.11ax
module
•
15μ Gold Contact in VGA PCIe Slot (PCIE1)
Graphics
•
Integrated AMD Radeon
TM
Vega Series Graphics in Ryzen
Series APU*
* Actual support may vary by CPU
•
DirectX 12, Pixel Shader 5.0
•
Shared memory default 2GB. Max Shared memory supports
up to 16GB.
* e Max shared memory 16GB requires 32GB system memory
installed.
•
Dual graphics output: support HDMI and DisplayPort 1.4
ports by independent display controllers
•
Supports HDMI 2.0 with max. resolution up to 4K x 2K
(4096x2160) @ 30Hz
•
Supports DisplayPort 1.4 with max. resolution up to 4K x 2K
(4096x2160) @ 120Hz
* DisplayPort 1.4 Input is used to connect a Type-C Monitor.
•
Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and
HBR (High Bit Rate Audio) with HDMI 2.0Ports (Compliant
HDMI monitor is required)
•
Supports HDR (High Dynamic Range) with HDMI 2.0
•
Supports HDCP 2.2 with HDMI 2.0and DisplayPort 1.4
Ports
•
Supports 4K Ultra HD (UHD) playback with HDMI 2.0and
DisplayPort 1.4 Ports
•
Supports Microso PlayReady®
