English
5
X570 Taichi
•
1 x USB 3.2 Gen2 Type-C Port (10 Gb/s) (Supports ESD
Protection)
•
6 x USB 3.2 Gen1 Ports (Supports ESD Protection)
* Ultra USB Power is supported on USB3_5_6 ports.
* ACPI wake-up function is not supported on USB3_5_6ports.
•
1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
•
1 x Clear CMOS Button
•
1 x BIOS Flashback Button
•
HD Audio Jacks: Rear Speaker / Central / Bass / Line in /
Front Speaker / Microphone (Gold Audio Jacks)
Storage
•
8 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0,
RAID 1 and RAID 10), NCQ, AHCI and Hot Plug
•
1 x Hyper M.2 Socket (M2_1), supports M Key type
2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI
Express module up to Gen4x4 (64 Gb/s) (with Matisse) or
Gen3x4 (32 Gb/s) (with Pinnacle Ridge and Picasso)*
•
1 x Hyper M.2 Socket (M2_2), supports M Key type
2260/2280 M.2 PCI Express module up to Gen4x4 (64 Gb/s)*
•
1 x Hyper M.2 Socket (M2_3), supports M Key type
2230/2242/2260/2280/22110 M.2 SATA3 6.0 Gb/s module
and M.2 PCI Express module up to Gen4x4 (64 Gb/s)*
* If M2_3 is occupied, PCIE5 slot will be disabled
* Supports NVMe SSD as boot disks
* Supports ASRock U.2 Kit
Connector
•
1 x SPI TPM Header
•
1 x Power LED and Speaker Header
•
1 x AMD Fan LED Header
* e AMD Fan LED Header is compatible with a regular RGB
LED stripe.
* e AMD Fan LED Header supports LED strips of maximum
load of 3A (36W) and length up to 2.5M.
•
1 x RGB LED Header
* Supports in total up to 12V/3A, 36W LED Strip
•
1 x Addressable LED Header
* Supports in total up to 5V/3A, 15W LED Strip
•
1 x CPU Fan Connector (4-pin)
