ASRock B550 Taichi [10/102] B550 taichi
![ASRock B550 Taichi [10/102] B550 taichi](/views2/1690372/page10/bga.png)
English
3
B550 Taichi
AMD Ryzen series APUs (Renoir)
•
3 x PCI Express x16 Slots (PCIE1/PCIE3/PCIE5: single at
Gen3x16 (PCIE1); dual at Gen3x8 (PCIE1) / Gen3x8 (PCIE3);
triple at Gen3x8 (PCIE1) / Gen3x8 (PCIE3) / Gen3x4
(PCIE5))*
* If PCIE2 or PCIE4 is occupied, PCIE5 will downgrade to x2
mode.
* Supports NVMe SSD as boot disks
•
2 x PCI Express 3.0 x1 Slots
•
Supports AMD Quad CrossFireX
TM
, 3-Way CrossFireX
TM
and CrossFireX
TM
•
1 x Vertical M.2 Socket (Key E) with the bundled WiFi-
802.11ax module (on the rear I/O)
•
15μ Gold Contact in VGA PCIe Slot (PCIE1)
Graphics
•
Integrated AMD Radeon
TM
Vega Series Graphics in Ryzen
Series APU*
* Actual support may vary by CPU
•
DirectX 12, Pixel Shader 5.0
•
Shared memory default 2GB. Max Shared memory supports
up to 16GB.
* e Max shared memory 16GB requires 32GB system memory
installed.
•
Dual graphics output: support HDMI and DisplayPort 1.4
ports by independent display controllers
•
Supports HDMI 2.1 with max. resolution up to 4K x 2K
(4096x2160) @ 60Hz
•
Supports DisplayPort 1.4 Input with max. resolution up to
5K (5120x2880)@120Hz
•
Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and
HBR (High Bit Rate Audio) with HDMI 2.1 Port (Compliant
HDMI monitor is required)
•
Supports HDR (High Dynamic Range) with HDMI 2.1
•
Supports HDCP 2.3 with HDMI 2.1 and DisplayPort 1.4
Ports
•
Supports 4K Ultra HD (UHD) playback with HDMI 2.1 and
DisplayPort 1.4 Ports
•
Supports Microso PlayReady®
