ASRock A520M Pro4 [9/88] English
![ASRock A520M Pro4 [9/88] English](/views2/1690482/page9/bg9.png)
English
4
LAN
•
PCIE x1 Gigabit LAN 10/100/1000 Mb/s
•
Realtek RTL8111H
•
Supports Wake-On-LAN
•
Supports Lightning/ESD Protection
•
Supports Energy Ecient Ethernet 802.3az
•
Supports PXE
Rear Panel
I/O
•
Antenna Bracket
•
1 x PS/2 Mouse/Keyboard Port
•
1 x D-Sub Port
•
1 x HDMI Port
•
1 x DisplayPort 1.4
•
1 x USB 3.2 Gen1 Type-A Port (Supports ESD Protection)
•
4 x USB 3.2 Gen1 Type-A Ports (ASMedia ASM1074 hub)
(Supports ESD Protection)
•
1 x USB 3.2 Gen1 Type-C Port (Supports ESD Protection)
•
2 x USB 2.0 Ports (Supports ESD Protection)
•
1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
•
HD Audio Jacks: Line in / Front Speaker / Microphone
Storage
•
4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0,
RAID 1 and RAID 10), NCQ, AHCI and Hot Plug*
* M2_2 and SATA3_3_4 share lanes. If either one of them is in
use, the other one will be disabled.
•
1 x Ultra M.2 Socket (M2_1), supports M Key type 2280 M.2
PCI Express module up to Gen3 x4 (32 Gb/s)**
•
1 x M.2 Socket (M2_2), supports M Key type 2280 M.2
SATA3 6.0 Gb/s module and M.2 PCI Express module up to
Gen3 x2 (16 Gb/s)**
** Supports NVMe SSD as boot disks
** Supports ASRock U.2 Kit
